纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (02-016[00]) - SHOE ASSEMBLY (600MM) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
836 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT60D00016F2 | [1] | 600mm | |
| 1. | YT60D00012F2 | [2] | SHOE | KOBAssy. |
| 2. | YT62D00007F1 | [1] | TRACK ASSY | KOBAssy. |
| 3. | 2424J175D1 | [39] | TRACK LINK | KOB |
| 4. | 2424J175D2 | [39] | TRACK LINK | KOB |
| 5. | YT62D01010P1 | [38] | BUSHING | KOB |
| 6. | YT62D01002P1 | [38] | PIN | KOB |
| 7. | YT62D01003P1 | [1] | BUSHING | KOB |
| 8. | YT62D01004P1 | [1] | PIN | KOB |
| 9. | YT62D01011P1 | [76] | SEAL | KOB |
| 10. | 2418T20891 | [2] | COLLAR | KOB |
| 11. | YT60D00009P1 | [39] | SHOE,600mm W | KOB |
| 12. | YT60D01001P1 | [156] | BOLT | KOB |
| 13. | YT60D01002P1 | [156] | NUT | KOB |
