纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (02-018[00]) - DOZER INSTALLATION New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
865 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT51B00059F1 | [1] | | |
| 1. | YT51B01109P1 | [2] | PIN | KOB |
| 2. | HS18C12100G2 | [2] | SCREW | KOBCap |
| 3. | ZN18C12010 | [4] | NUT | KOB |
| 4. | 2445R138D1 | [4] | SEAL,50mm ID x 64mm OD | KOBDust |
| 5. | B16T0442D25 | [2] | SHIM,80mm OD x 52mm ID x 1.2mm Thk | KOB |
| 6. | B16T0442D23 | [2] | SHIM,80mm OD x 52mm ID x 1.6mm Thk | KOB1.6 |
| 7. | B16T0442D24 | [2] | SHIM,80mm OD x 52mm ID x 2.3mm Thk | KOB |
