凯斯零件查询(ADX2230) - AIR DELIVERY SYSTEM (6/01-7/08) (D.13.B[07]) - DUAL HUB 5.5 INCH SPACING Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
870 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87340
|
[20] |
LOCK WASHER,Helical Spring, 0.759" ID, CST, ZND
|
NH
|
| 2. |
9707580
|
[6] |
BOLT,Hex, 1/4" - 20 x 3/4", Gr 5, Full Thd
|
NH
|
| 3. |
86512049
|
[20] |
BOLT,Hex, 3/4" - 16 x 3", Gr 8
|
BHB
|
| 4. |
9823966
|
[20] |
NUT,3/4"-16, G8
|
WIN
|
| 5. |
86613381
|
[1] |
ROLLER BEARING,114.3mm ID x 41.27mm W
|
WIN
#64450 Superseded by part number: 86613383
|
| 6. |
16-16
|
[1] |
BEARING
|
CAS
#64700 Superseded by part number: 86613383
|
| 7. |
51200892
|
[1] |
SEAL
|
FLX
5 5/8" id, CR # 56160
|
| 8. |
51200893
|
[1] |
SPINDLE
|
FLX
dual wheel - 5 5/8" x 44 31/64"
|
| 9. |
461-4108
|
[5] |
HEX SOC SCREW,#10 - 24 x 1/2"
|
CAS
|
| 10. |
9781
|
[1] |
SLEEVE
|
FLX
thrust - dual wheel hub
|
| 11. |
9782
|
[2] |
NUT
|
FLX
4 1/8"
|
| 12. |
9783
|
[1] |
HUB CAP
|
FLX
dual wheel
|
| 13. |
237698A1
|
[1] |
BEARING CUP,212.74mm OD x 53.87mm W
|
CAS
#932 Superseded by part number: 73133298
|
| 14. |
9785
|
[1] |
ROLLER BEARING
|
FLX
#936
|
| 15. |
9788
|
[1] |
LOCK WASHER
|
FLX
spindle 4 1/8"
|
| 16. |
21681
|
[2] |
RING
|
FLX
sensor half of 60 tooth
|
| 17. |
51200894
|
[1] |
HUB
|
FLX
dual wheel
|
