| 89. | 2416Z472D13 | [1] | STRIP, WEATHER | |
| 90. | 2427R659 | [1] | PAD | |
| 91. | 24100J6436S91 | [1] | GLASS | KOB |
| 92. | 24100J6436S92 | [1] | RUBBER | |
| 94. | 24100J6436S94 | [2] | COVER | KOB |
| 95. | 24100J6436S95 | [4] | BOLT | KOB Superseded by part number: 24100J6512S220 |
| 96. | 24100J6107S162 | [4] | LOCK WASHER | KOB Superseded by part number: ZW16X08000 |
| 97. | 24100J6107S161 | [4] | LOCK WASHER | KOB Superseded by part number: 83990583 |
| 99. | 2427U318 | [1] | FRAME | KOBWINDOW |
| 99-11. | ZR36X00800 | [5] | SNAP RING | KOB |
| 99-12. | 2425Z508 | [4] | BALL BEARING | KOB Superseded by part number: 2425Z8 |
| 100. | 24100J6436S100 | [1] | GLASS | KOB |
| 101. | 2416Z472D5 | [1] | RUBBER STRIP, WEATHER | RUBBER STRIP, WEATHER |
| 102. | 2479R704 | [1] | WIPER | KOB Superseded by part number: YT53C00011F1 |
| 103. | 24100J6436S103 | [1] | TOOL | |
| 104. | 2479R703 | [1] | WIPER ARM | KOB Superseded by part number: 2488R249 |
| 105. | R79P0021D2 | [1] | WIPER BLADE | KOB Superseded by part number: 2488Z8D4 |
| 106. | 24100J6436S106 | [1] | WIRE HARNESS | KOB |
| 107. | 24100J6436S107 | [2] | STOP | KOB Superseded by part number: 24100J6512S130, PY06C01040P1 |
| 108. | 24100J6436S108 | [2] | NUT | KOB |
| 109. | 2416Z471D2 | [1] | RUBBER SLEEVE | KOB |
| 110. | 2427T863 | [1] | PLATE | KOB |
| 112. | 2416P7231 | [1] | STAY | KOB |
| 113. | ZW16X16000 | [1] | WASHER | KOBID 16 x OD 30 x Th 3.2mm |
| 114. | ZW26X16000 | [1] | LOCK WASHER | KOBID 16 x OD 28 x Th 4.0mm |
| 115. | ZS18C16045 | [1] | SCREW,Hex, M16 x 45mm | KOBM16x2.0x45mm |
| 116. | 2416Z466 | [2] | STOP | KOB |
| 117. | 2416R223 | [1] | BRACKET | KOB |
| 118. | 24100J6436S118 | [1] | BRACKET, LATCH | |
| 119. | 24100J6436S119 | [7] | BOLT, SET | |
| 120. | 24100J6107S160 | [1] | NUT | KOB |
| 123. | 24100J6284S123 | [1] | BUSHING | |
| 124. | 24100J6436S124 | [1] | BUSHING | |
| 126. | 2416Z469D2 | [2] | SEAL, RUBBER | SEAL, RUBBER |
| 127. | 2416Z469D3 | [2] | SEAL, RUBBER | SEAL, RUBBER |
| 128. | 2427Z543 | [1] | TERMINAL CONNECTOR | KOB |
| 129. | 24100J6107S74 | [2] | SETSCREW | SETSCREW |
| 130. | 24100J6107S75 | [2] | SCREW,Phillips Drive, Pan HD, M3 x 10mm | KOB Superseded by part number: ZS31C03010 |
| 131. | 24100J6107S76 | [2] | NUT | NUT |
| 132. | 24100J6436S132 | [1] | HARNESS | |
| 140. | 24100J6284S140 | [1] | GROMMET | |
| 143. | 24100J6436S143 | [1] | GUARD, Start Serial: YG0647 | |
| . . | 2414R260 | [1] | GUARD, Start Serial: YG0660 | |
| 144. | 24100J6436S144 | [1] | GUARD, Start Serial: YG0647 | |
| . . | 2414R258 | [1] | GUARD, Start Serial: YG0660 | GUARD, Start Serial: YG0660 |
| 145. | 24100J6436S145 | [1] | GUARD, Start Serial: YG0647 | |
| . . | 2414R261 | [1] | GUARD, Start Serial: YG0660 | GUARD, Start Serial: YG0660 |
| 146. | 24100J6436S146 | [6] | BOLT | KOB, Start Serial: YG0647 |
| . . | 24100J6436S146 | [7] | BOLT | KOB, Start Serial: YG0660 |
| 147. | 24100J6436S147 | [1] | GUARD, Start Serial: YG0647 | |
| . . | 2414R254 | [1] | GUARD, Start Serial: YG0660 | GUARD, Start Serial: YG0660 |
| 148. | 24100J6436S148 | [1] | GUARD, Start Serial: YG0647 | |
| . . | 2414R252 | [1] | GUARD, Start Serial: YG0660 | GUARD, Start Serial: YG0660 |
| 149. | 24100J6436S149 | [1] | GUARD, Start Serial: YG0647 | |
| . . | 2414R256 | [1] | GUARD, Start Serial: YG0660 | GUARD, Start Serial: YG0660 |
| 150. | 24100J6436S150 | [1] | GUARD, Start Serial: YG0647 | |
| . . | 2414R259 | [1] | GUARD, Start Serial: YG0660 | GUARD, Start Serial: YG0660 |
| 151. | 24100J6436S151 | [1] | GUARD, Start Serial: YGYG0647 | |
| . . | 2414R251 | [1] | GUARD, Serial Range: YG0660-YG0752 | |
| 152. | 2414R250 | [1] | GUARD, Serial Range: YG0647-YG0752 | |
| 153. | 2414R253 | [1] | GUARD, Start Serial: YG0660 | |
| 154. | 2414R257 | [1] | GUARD, Start Serial: YG0660 | GUARD, Start Serial: YG0660 |
| 155. | 2414R255 | [1] | GUARD, Start Serial: YG0660 | |
| 156. | 2414R262 | [1] | GUARD, Start Serial: YG0753 | GUARD, Start Serial: YG0753 |
| 157. | 2414R263 | [1] | GUARD, Start Serial: YG0753 | GUARD, Start Serial: YG0753 |
