神钢零件查询(MD180LC) - EXCAVATOR ASN YG0647 (1/80-12/06) (02-003) - PLATE ASSY, FLOOR Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
808 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N2997F4 | [1] | PLATE ASSY, FLOOR | |
| 1. | 2422N835 | [1] | PLATE, FLOOR | |
| 2. | 2414T2673 | [12] | COVER | KOB |
| 3. | 2416Z253D2 | [12] | RUBBER SLEEVE | KOB |
| 4. | 2418T9226D5 | [6] | SPACER | KOB |
| 5. | ZS18C16100 | [6] | SCREW,Hex, M16 x 100mm | KOBM16x2.0x100mm |
| 6. | ZN32C16015 | [6] | NUT | KOBM16x2.0mm |
| 7. | R16T0152D2 | [12] | WASHER | KOBFlat -- ID 17 x OD 30 x Th 3.2mm |
| 8. | 2422T547 | [2] | STEP | |
| 9. | 2416P8622 | [1] | BRACKET | KOB |
| 10. | ZS18C10025 | [11] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 11. | ZW26X10000 | [11] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 14. | 2416N3251 | [1] | STAND | STAND |
| 15. | 2414P3977 | [1] | COVER | COVER |
| 16. | ZM11C06016 | [9] | BOLT | KOB |
| 17. | ZW16X06000 | [9] | WASHER | KOBID 06 x OD 12.5 x Th 1.6mm Superseded by part number: 86588450 |
| 18. | 24100P1137F2 | [1] | BOX ASSY | |
| 18-7. | 2421Z295 | [2] | LOCK | KOB |
| 18-8. | 2421N162 | [1] | BOX | |
| 18-9. | 2414P3998 | [1] | COVER | |
| 18-10. | 2414P3999 | [1] | COVER | |
| 18-11. | 2420Z1192 | [14] | RIVET | KOBRIVET |
| 18-12. | 2416Z503D1 | [4] | RUBBER, CUSHION | |
| 18-13. | 2416Z503D2 | [1] | RUBBER, CUSHION | |
| 18-14. | 2416Z503D3 | [1] | RUBBER, CUSHION | |
| 27. | 2427J1295D3 | [1] | FLOOR MAT | KOB |
