纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-017[01]) - VALVE INSTALLATION New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
954 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LF64H00048F1 | [1] | | |
| 1. | YT64H00093F1 | [1] | CONTROL VALVE | KOBInstal |
| 2. | YT64H01149P1 | [1] | BRACKET | KOB |
| 3. | YT64H01170P1 | [1] | BRACKET | KOB |
| 4. | YT64H01164P1 | [1] | STAY | KOB |
| 5. | YT64H01153P1 | [1] | STAY | KOB |
| 6. | ZM73C12030 | [2] | BOLT,M12x30mm - Course Thread | KOBSems |
| 7. | ZM73C12035 | [11] | BOLT,M12x35mm - Course Thread | KOBSems |
| 8. | YN64H01393D1 | [2] | CAP | KOB |
| 9. | YN64H01391D1 | [1] | CAP | KOB |
