凯斯零件查询(2501) - CONCORD AIR SYSTEM (1/95-11/01) (15) - TANK COVER Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
566 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
1015904
|
[1] |
COVER ASSEMBLY
|
|
| 2. |
1015941
|
[2] |
SPACER, pivot
|
|
| 3. |
1011607
|
[2] |
BOLT
|
L
BOLT, hex, 1/2" x 1 1/2" Superseded by part number: 87689
|
| 4. |
1014443
|
[4] |
WASHER
|
CAS
flat Superseded by part number: 80700
|
| 5. |
1011097
|
[2] |
NUT,1/2"-13, G5
|
CAS
hex, 1/2" Superseded by part number: 280431
|
| 6. |
1015067
|
[1] |
GRILLE
|
CON
GRILL ASSEMBLY Superseded by part number: 1026562
|
| 8. |
1013286
|
[4] |
TOGGLE
|
CON
TOGGLE ASSEMBLY
|
| 9. |
1015906
|
[2] |
GASKET
|
L
cover
|
| 10. |
1015196
|
[4] |
U-BOLT
|
L
TOGGLE
|
| 11. |
1015907
|
[2] |
GASKET
|
L
cover
|
| 12. |
1015928
|
[1] |
CHAIN
|
CARRIER
|
| 13. |
1016491
|
[1] |
REPAIR LINK, chain
|
|
| 14. |
1016490
|
[1] |
HOSE,1.00" ID x 26.75"
|
CON
- Chain protector 1.00" ID x 26.75"
|
