现代零件查询R500LC-7A SWING MOTOR(TYPE2, #0130-)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
926 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
31QB-10150
|
[1] |
SWING MOTOR ASSY-LH
|
|
| . |
31QB-10170
|
[1] |
SWING MOTOR ASSY-RH
|
|
| -1. |
31QB-10130
|
[1] |
SWING MOTOR UNIT-LH
|
|
| -1. |
31QB-10160
|
[1] |
SWING MOTOR UNIT-RH
|
|
| 1. |
XKAY-00637
|
[1] |
BODY
|
|
| K2. |
XKAY-00521
|
[1] |
SEAL-OIL
|
|
| 3. |
XKAY-00522
|
[1] |
BEARING-ROLLER
|
|
| 4. |
XKAY-00523
|
[1] |
RING-SNAP
|
|
| 5. |
XKAY-01317
|
[1] |
SHAFT
|
|
| 6. |
XKAY-00525
|
[1] |
BUSHING
|
|
| 7. |
XKAY-00526
|
[1] |
RING-STOP
|
|
| 8. |
XKAY-00625
|
[1] |
PIN
|
|
| 9. |
XKAY-00527
|
[1] |
PLATE-SHOE
|
|
| A. |
XKAY-00635
|
[1] |
ROTARY KIT
|
|
| A-A. |
XKAY-00634
|
[1] |
CYLINDER BLOCK KIT
|
|
| 10. |
XKAY-00633
|
[1] |
BLOCK-CYLINDER
|
|
| 11. |
XKAY-00531
|
[9] |
SPRING
|
|
| 24. |
XKAY-00544
|
[1] |
PLATE-VALVE
|
|
| A-B. |
XKAY-00532
|
[1] |
RETAINER KIT
|
|
| 12. |
XKAY-00533
|
[1] |
GUIDE-BALL
|
|
| 13. |
XKAY-00534
|
[1] |
PLATE-SET
|
|
| A-C. |
XKAY-00535
|
[1] |
PISTON KIT
|
|
| N14. |
XKAY-00536
|
[9] |
PISTON ASSY
|
|
| 15. |
XKAY-00537
|
[3] |
PLATE-FRICTION
|
|
| 16. |
XKAY-00538
|
[3] |
PLATE
|
|
| 17. |
XKAY-00632
|
[1] |
PISTON-BRAKE
|
|
| K18. |
XKAY-00468
|
[1] |
O-RING
|
|
| K19. |
XKAY-00540
|
[2] |
O-RING
|
|
| 20. |
XKAY-00541
|
[20] |
SPRING
|
|
| 21. |
XKAY-01319
|
[1] |
COVER-REAR
|
|
| 22. |
XKAY-00543
|
[1] |
BEARING-NEEDLE
|
|
| 23. |
XKAY-00382
|
[2] |
PIN
|
|
| 25. |
XKAY-00546
|
[4] |
BOLT-WRENCH
|
|
| 26. |
XKAY-00309
|
[2] |
PLUG
|
|
| K27. |
XKAY-00141
|
[2] |
RING-BACK UP
|
|
| K28. |
XKAY-00310
|
[2] |
O-RING
|
|
| 29. |
XKAY-00311
|
[2] |
SPRING
|
|
| 30. |
XKAY-00312
|
[2] |
CHECK
|
|
| 31A. |
XKAY-01475
|
[1] |
RELIEF VALVE ASSY
|
|
| 31B. |
XKAY-01476
|
[1] |
RELIEF VALVE ASSY
|
|
| 32. |
XKAY-00314
|
[2] |
VLV ASSY-REACTIONLESS
|
|
| 33. |
XKAY-01318
|
[1] |
TIME DELAY VALVE ASSY
|
|
| 34. |
XKAY-00149
|
[3] |
BOLT-WRENCH
|
|
| 35. |
XKAY-00150
|
[3] |
PLUG
|
|
| K36. |
XKAY-00151
|
[3] |
O-RING
|
|
| 37. |
XKAY-00140
|
[1] |
PLUG
|
|
| 38. |
XKAY-00975
|
[1] |
PLUG
|
|
| 39. |
XKAY-00548
|
[1] |
PLUG
|
|
| 40. |
XKAY-01477
|
[1] |
NAME PLATE
|
|
| 40. |
XKAY-01478
|
[1] |
NAME PLATE
|
|
| 41. |
XKAY-00277
|
[2] |
RIVET
|
|
| 42. |
XKAY-00638
|
[1] |
LEVEL GAUGE
|
|
| 42-1. |
XKAY-02139
|
[1] |
BAR-GAUGE
|
|
| 43. |
XKAY-00322
|
[2] |
PLUG
|
|
| K44. |
XKAY-00324
|
[2] |
O-RING
|
|
| K45. |
XKAY-00247
|
[2] |
O-RING
|
|
| K46. |
XKAY-00605
|
[2] |
RING-BACK UP
|
|
| -2. |
@
|
[1] |
SWING REDUCTION GEAR
|
|
| K. |
XKAY-00553
|
[1] |
SEAL KIT
|
|
| N. |
@
|
[1] |
NOT SUPPLIED PARTS
|
|
