凯斯零件查询(3400) - CONCORD AIR SYSTEM (1/96-12/00) (E04) - DRAWPOLE & STEERING LINKAGE 3503, 3400 & 2300 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
445 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
1021777
|
[1] |
DRAWBAR
|
CON
WLDMT - drawpole
|
| 2. |
1027881
|
[1] |
HITCH PIN
|
CAS
ASSY - hitch pin
|
| 3. |
1016961
|
[1] |
JACK
|
CAS
STAND 450TT215
|
| 4. |
1021005
|
[4] |
BUSHING
|
CAS
- AA-2001-9
|
| 5. |
86636814
|
[12] |
LUBE NIPPLE,1/4"-28 x .52" lg
|
GI
ZERK - grease: .25 UNF STR Superseded by part number: 88775
|
| 6. |
1020674
|
[1] |
PIN
|
CAS
WLDMT - tongue hinge bolt (13.5" long)
|
| 7. |
1020675
|
[4] |
LOCK WASHER
|
CAS
- star: INT 1.25 ZP
|
| 8. |
1020676
|
[6] |
LOCK NUT
|
CON
NUT - jam: 1.25 NF GR2 ZP (Order 425-1520) Superseded by part number: 425-1520
|
| 9. |
1020752
|
[1] |
HITCH ASSY, TRAILER
|
CAS
WLDMT - hitch
|
| 10. |
1021294
|
[1] |
BAR
|
CAS
- stop
|
| 11. |
1011595
|
[2] |
BOLT,Hex, 1/4" - 20 x 3/4", Gr 5, Full Thd
|
CON
BOLT - hex: .25 x .75 NC GR5 ZP (Order 413-412) Superseded by part number: 9707580
|
| 12. |
1020796
|
[1] |
PIN
|
CAS
WLDMT - king pin hitch
|
| 13. |
1020753
|
[1] |
BRACKET
|
CAS
- hitch
|
| 14. |
1017708
|
[2] |
BOLT
|
CON
BOLT - hex: .50 x 2.25 NC GR5 ZP (Order 413-836) Superseded by part number: 87975
|
| 15. |
1020756
|
[1] |
BLOCK
|
CAS
- spacer
|
| 16. |
1011613
|
[2] |
BOLT
|
CON
BOLT - hex: .50 x 4.00 NC GR5 ZP (Order 413-864) Superseded by part number: 86505993
|
| 17. |
1020678
|
[1] |
PIN
|
CAS
WLDMT - king pin hitch
|
| 18. |
425-1314
|
[1] |
SLOTTED NUT,7/8"-14, G5
|
CAS
NUT - hex: slot .88 NF GR5 ZP Superseded by part number: 84151573
|
| 19. |
1012375
|
[1] |
SPLIT PIN/SAFETY PIN
|
CON
PIN - cotter: .19 x 1.50 NP (Order 432-1244) Superseded by part number: 80754
|
| 20. |
1020682
|
[2] |
ROD
|
CAS
WLDMT - tie rod
|
| 21. |
1020681
|
[2] |
BUSHING
|
CAS
- AA-1214-6
|
| 22. |
1020683
|
[2] |
CLEVIS
|
CAS
WLDMT - tie rod clevis
|
| 23. |
CAS1024351
|
[2] |
ROD
|
CAS
ASSY - tie rod bolt
|
| 24. |
425-1316
|
[2] |
NUT,1"-14, G5
|
CAS
NUT - hex: slot 1-14 NS GR2 ZP (Order 425-1316) Superseded by part number: 86020752
|
| 25. |
1013473
|
[2] |
ANGLE BAR
|
CON
PIN - cotter: .19 x 2.00 NP (Order 432-1232) Superseded by part number: 87400
|
| 26. |
1011747
|
[2] |
FITTING
|
CON
ZERK - grease: .25-28 NFT 45D
|
| 27. |
0100615
|
[2] |
BOLT
|
CON
- hex: .19 x .75 NC GR5 ZP
|
| 28. |
1029645
|
[2] |
LOCK WASHER
|
CAS
- lock .19 ZP
|
| 30. |
1023331
|
[1] |
BOLT
|
CAS
BOLT - hex: 1.00 x 2.50 NC GR5 ZP Superseded by part number: 16505
|
| 31. |
1032161
|
[1] |
CHAIN (AG)
|
CAS
CHAIN - safety 10.1K PC #8601553 Superseded by part number: 100682C3
|
| 32. |
1032169
|
[1] |
WASHER
|
CAS
- heavy duty
|
| 33. |
1013430
|
[1] |
LOCK NUT
|
CAS
NUT - centerlock: 1.00 NC GR2 ZP Superseded by part number: 232-14416
|
