凯斯零件查询(2230) - PRECISION AIR CART (1/02-12/08) (55.404.08) - TRANSPORT BAR AMBER LIGHT EXTENSION Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
465 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
425270A1
|
[1] |
HARNESS
|
FLX
jumper 3 m x 2c Packard
|
| 2. |
87692855
|
[1] |
CONTACT HOUSING,Male, 2 Cavities
|
BN
plastic 2c plug
|
| 3. |
225123C1
|
[2] |
TERMINAL CONNECTOR,Tin, 0.8mm
|
IH
socket 18-20awg
|
| 4. |
225124C1
|
[4] |
SEAL,2 - 2.9 mm2
|
IH
seal grn 2.8-2 omm Superseded by part number: 84286327
|
| 5. |
87692877
|
[1] |
MULTIPOLE CONNECTOR,Male, 2 Cavities
|
BN
plastic 2c receptacle
|
| 6. |
225120C1
|
[2] |
TERMINAL CONNECTOR,Tin, 0.8mm
|
IH
18-20awg
|
