凯斯零件查询(2230) - PRECISION AIR CART (1/02-12/08) (58.120.02) - AUGER TUBE ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
641 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
88731
|
[2] |
BOLT,Hex, 5/16"- 18 x 3", Gr 5
|
NH
|
| 2. |
80681
|
[2] |
LOCK NUT,5/16"
|
NH
Superseded by part number: 83990583
|
| 3. |
88206
|
[12] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
NH
|
| 4. |
80664
|
[3] |
WASHER,0.38" ID x 0.88" OD x 0.08" Thk
|
NH
|
| 5. |
88902
|
[2] |
NUT,3/8"-16
|
NH
|
| 6. |
9628503
|
[8] |
NUT,3/8"-16, G5
|
NH
|
| 7. |
80680
|
[12] |
LOCK WASHER,3/8 0.381 CST ZND
|
NH
|
| 8. |
438-12024
|
[1] |
LOCK PIN,5/16" x 1 1/2", Slotted
|
CAS
|
| 9. |
8559
|
[1] |
PIN,5/16" x 3"
|
FLX
roll 5/16" x 3", Slotted
|
| 10. |
87415457
|
[1] |
SEAL KIT
|
SAS
hydraulic valve rotary
|
| 11. |
5171
|
[1] |
HOSE CLAMP
|
FLX
#128 type f 6 1/2" to 8 1/2"
|
| 12. |
419995A1
|
[1] |
HOSE
|
FLX
7" x 32" auger discharge
|
| 13. |
87448320
|
[1] |
HYDRAULIC MOTOR
|
SAS
white 76cc
|
| 13. |
87447941
|
[1] |
SEAL KIT
|
SAS
hydraulic motor white 76cc Superseded by part number: 86529014
|
| 14. |
9635082
|
[2] |
NUT,5/16" - 18, Gr 5
|
NH
|
| 15. |
51200111
|
[2] |
HANDLE
|
FLX
61/64" x 4 3/8" yellow
|
| 16. |
87415456
|
[1] |
HYDRAULIC VALVE
|
SAS
rotary
|
| 17. |
280188
|
[1] |
BOLT,Hex, 3/8" - 16 x 2 3/4", Gr 8
|
GI
|
| 18. |
443822A1
|
[1] |
DECAL
|
SAS
auger direction 2 panel pictorial Europe
|
| 20. |
84307616
|
[2] |
CLAMP
|
SAS
plastic, hydraulic tube
|
| 21. |
GR-430
|
[1] |
TUBE,11.375" OD x 188.812" L
|
SAS
8" auger
|
| 22. |
GR-431
|
[1] |
HANDLE
|
SAS
auger end
|
| 23. |
GR-432
|
[1] |
CONTROL
|
SAS
auger valve top
|
| 24. |
GR-436
|
[1] |
CONTROL
|
SAS
auger valve bottom
|
