现代零件查询R500LC-7A TRAVEL MOTOR(1/2, TYPE 2)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
962 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| N . |
31NB-40030
|
[1] |
TRAVEL MOTOR ASSY
|
|
| N -1. |
XKAH-01317
|
[1] |
CONTROL PART
|
|
| N -11. |
XKAH-01318
|
[1] |
REAR FLANGE ASSY
|
|
| N -12. |
XKAH-01319
|
[1] |
REAR FLANGE KIT
|
|
| N1. |
XKAH-01320
|
[1] |
REAR FLANGE
|
|
| -121. |
XKAH-01563
|
[1] |
SPOOL ASSY-CB
|
|
| N2. |
XKAH-01322
|
[2] |
SPOOL-CB
|
|
| N3. |
XKAH-01323
|
[2] |
POPPET
|
|
| N4. |
XKAH-01564
|
[2] |
PLUG
|
|
| N5. |
XKAH-01325
|
[2] |
SPRING-CHECK
|
|
| N8. |
XKAH-01326
|
[2] |
SEAT
|
|
| N9. |
XKAH-01327
|
[2] |
BALL-STEEL
|
|
| N10. |
XKAH-01328
|
[2] |
SPRING
|
|
| N11. |
XKAH-01329
|
[2] |
SCREW
|
|
| 6. |
XKAH-01330
|
[2] |
SPRING-MAIN
|
|
| 7. |
XKAH-01331
|
[2] |
WASHER
|
|
| 12. |
XKAH-01332
|
[2] |
COVER-CB
|
|
| 13. |
XKAH-00961
|
[2] |
O-RING
|
|
| 14. |
XKAH-00962
|
[8] |
BOLT-SOCKET
|
|
| 26. |
XKAH-01334
|
[1] |
O-RING
|
|
| 41. |
XKAH-00187
|
[1] |
PIN-VALVE PLATE
|
|
| 43. |
XKAH-00144
|
[8] |
BOLT-SOCKET
|
|
| 45. |
XKAH-00327
|
[2] |
PLUG-PT
|
|
| 50. |
XKAH-00943
|
[1] |
BEARING-NEEDLE
|
|
| 52. |
XKAH-00050
|
[2] |
PLUG-RO
|
|
| 54. |
XKAH-00625
|
[8] |
PLUG
|
|
| 56. |
XKAH-00136
|
[2] |
PLUG-VP
|
|
| 65. |
XKAH-01554
|
[1] |
SPOOL-2P
|
|
| 66. |
XKAH-01555
|
[1] |
SPRING-2P
|
|
| 68. |
XKAH-00056
|
[2] |
BALL-STEEL
|
|
| 72. |
XKAH-01565
|
[1] |
ORIFICE
|
|
| 73. |
XKAH-01566
|
[1] |
ORIFICE
|
|
| 74. |
XKAH-00052
|
[4] |
O-RING
|
|
| N82. |
XKAH-01556
|
[1] |
PLUG
|
|
| 83. |
XKAH-00035
|
[1] |
O-RING
|
|
| 98. |
XKAH-01557
|
[2] |
PLATE-NAME
|
|
| 99. |
XKAH-00116
|
[2] |
SCREW-RIVET
|
|
| 500. |
XKAH-00956
|
[1] |
VALVE-REDUCING
|
|
| 501. |
XKAH-00957
|
[1] |
COVER
|
|
| -2. |
XKAH-01567
|
[2] |
RELIEF VALVE ASSY
|
|
| N401. |
XKAH-01359
|
[1] |
PLUNGER
|
|
| N402. |
XKAH-01360
|
[1] |
SEAT
|
|
| N403. |
XKAH-01568
|
[1] |
BODY
|
|
| 404. |
XKAH-00107
|
[1] |
RING-BACK UP
|
|
| 405. |
XKAH-00105
|
[3] |
O-RING
|
|
| N406. |
XKAH-01362
|
[1] |
O-RING
|
|
| N407. |
XKAH-01363
|
[1] |
RETAINER-SPRING
|
|
| N408. |
XKAH-01364
|
[1] |
SPRING
|
|
| N409. |
XKAH-01569
|
[1] |
PISTON
|
|
| N412. |
XKAH-01367
|
[1] |
PLUG-ADJUST
|
|
| N413. |
XKAH-01150
|
[1] |
NUT-LOCK
|
|
| N414. |
XKAH-01368
|
[1] |
SHIM
|
|
| -3. |
@
|
[1] |
HYD MOTOR ASSY
|
|
| -4. |
@
|
[1] |
REDUCTION PART
|
|
