神钢零件查询(MD180LC) - EXCAVATOR ASN YG0647 (1/80-12/06) (11-022) - CYLINDER ASSY ( L.H. BOOM) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
369 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2438U981F1 | [1] | CYLINDER ASSY L.H. BOOM, CONSISTS OF THE FOLLOWING PARTS | CYLINDER ASSY L.H. BOOM, CONSISTS OF THE FOLLOWING PARTS |
| 1. | 2438U980S1 | [1] | TUBE, CYLINDER | |
| 2. | ZS23C18075 | [8] | SCREW,Hex Socket Head, M18 x 75mm | KOBM18x2.50x75mm |
| 3. | 2438U914D1S3 | [1] | ORIFICE | KOB |
| 4. | 2438U980S4 | [1] | ROD, PISTON | |
| 5. | 2438U624S4 | [2] | BUSHING | KOB |
| 6. | 2445R138D7 | [4] | SEAL,80mm ID x 95mm OD x 4mm Thk | KOBDust -- ID 80 x OD 95 x Th 4mm |
| 7. | 2438U980S7 | [1] | PISTON | |
| 8. | 2438U980S8 | [1 SET] | SEAL | KOBPISTON |
| 10. | 2438U914D1S10 | [4] | WEAR RING | KOB |
| 11. | 2438U914D1S11 | [1] | NUT | KOB |
| 12. | 2438U914D1S12 | [1] | RING CUSHION | RING CUSHION |
| 13. | 2438U914D1S13 | [1] | COVER, ROD | COVER, ROD |
| 14. | 2438U914D1S14 | [1] | O-RING | KOB |
| 15. | ZD12P11500 | [1] | O-RING | KOBID 114.60 ± 0.94 x OD 125mm |
| 16. | 2438U914S27 | [1] | BACK-UP RING | KOB |
| 17. | 2438U1261S16 | [1] | BUSHING | KOB |
| 18. | 2438U278S24 | [1] | CLIP | KOB |
| 19. | 2438U278S25 | [1] | RING | KOB Superseded by part number: R45P0050D3 |
| 20. | 45Z91D125 | [1] | O-RING | KOB |
| 21. | 2438U914D1S21 | [1] | PACKING | KOB Superseded by part number: 2438U307S35 |
| 22. | 2438U914S28 | [1] | DUST CAP | KOB Superseded by part number: 2438U914D1S28 |
| 23. | 2438U914D1S23 | [1] | BRACKET | BRACKET |
| 24. | 2438U914D1S24 | [1] | U-BRACKET | KOB |
| 25. | ZS16C10035 | [2] | SCREW | KOBM10x1.50x35mm Superseded by part number: ZS18C10035 |
| 26. | ZW26X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| . . | 2438U914R100 | [1] | REPAIR KIT | KOBCONSISTS OF ITEM 14-16, 19-22 |
| . . | 2438U980R100 | [1] | REPAIR KIT | KOBCONSISTS OF ITEM 8, 10 |
| . . | 2438U980R110 | [1] | CONSISTS OF ITEM 1-8, 10-22 | |
