| . . | 24100J6151F8 | [1] | CONTROL ASSY, Start Serial: YG0647 | |
| . . | 24100J6151F13 | [1] | CONTROL ASSY, Start Serial: YG0660 | |
| 2. | 2406T1702 | [2] | PLATE | KOB |
| 3. | ZS13C10030 | [16] | SCREW | KOBM10x1.50x30mm Superseded by part number: ZS18C10030 |
| 4. | ZW26X10000 | [20] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 5. | 2406T1672 | [4] | YOKE | KOB Superseded by part number: 2406T2278 |
| 6. | 2419T3642D1 | [6] | PIN | KOB Superseded by part number: 2419T3784D1 |
| 7. | ZW16X12000 | [8] | WASHER | KOBID 12 x OD 24 x Th 2.3mm |
| 8. | 2419R9D4 | [8] | COTTER PIN | KOBSnap -- OD 12mm x 35.8mm Long |
| 9. | 2406R223D10 | [2] | WIRE HARNESS | KOB |
| 12. | ZS23C08020 | [4] | SCREW,Hex Socket Head, M8 x 20mm | KOBM08x1.25x20mm |
| 13. | ZW22K08000 | [4] | LOCK WASHER | KOBID 08 x OD 13 x Th 2.0mm |
| 14. | 2406T1807 | [2] | LEVER | LEVER |
| 14-2. | 2405R61D7 | [1] | BUSHING | KOB Superseded by part number: 2405U104D012008 |
| 15. | 2406T1762 | [2] | YOKE | KOB |
| 17. | ZW11X10000 | [6] | WASHER | KOBID 10 x OD 21 x Th 2.0mm Superseded by part number: ZW16X10000 |
| 18. | 2419R9D3 | [2] | PIN | KOBHair -- OD 10mm x 32.6mm Long |
| 19. | 2419T3757D3 | [2] | PIN | KOB |
| 21. | 2414P3934 | [1] | COVER | KOB |
| 23. | ZW26X06000 | [5] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 24. | 2414N1938 | [1] | COVER | KOB |
| 25. | 2416P8600 | [1] | SUPPORT | |
| 26. | 2419T4642 | [1] | PIN | KOB |
| 27. | 2416R231 | [1] | GRILLE | KOB |
| 28. | 2420Z1040 | [4] | SCREW | KOB |
| 32. | ZW26X08000 | [4] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 37. | ZS13C08020 | [4] | SCREW | KOBM08x1.25x20mm Superseded by part number: ZS18C08020 |
| 45. | ZS18C06016 | [5] | SCREW,Hex, M6 x 16mm | KOBM06x1.0x16mm |
| 46. | 24100N3035F2 | [1] | LEVER ASSY | LEVER ASSY |
| 46-1. | 2416N3254 | [1] | BRACKET | KOB |
| 46-2. | 2406P2608 | [1] | LEVER | KOB |
| 46-3. | 2414Z270D1 | [1] | CAP | KOB |
| 46-4. | ZP45X12080 | [1] | PIN | PIN |
| 46-5. | ZW16X12000 | [1] | WASHER | KOBID 12 x OD 24 x Th 2.3mm |
| 46-6. | ZP15D04022 | [1] | COTTER PIN | KOBPin, Cotter |
| 46-7. | ZS18C12030 | [1] | SCREW,Hex, M12 x 30mm | KOBM12x1.75x30mm |
| 46-8. | 2406T1812 | [1] | BAR | KOB |
| 46-10. | 2479Z954 | [1] | SWITCH | KOB |
| 46-11. | ZN17C12010 | [1] | NUT | KOBM12x1.75mm Superseded by part number: ZN18C12010 |
| 46-12. | ZW11X08000 | [1] | WASHER | KOBID 09 x OD 17 x Th 1.6mm Superseded by part number: ZW16X08000 |
| 46-13. | 2417T513 | [1] | SPRING | SPRING |
| 47. | ZW16X06000 | [5] | WASHER | KOBID 06 x OD 12.5 x Th 1.6mm Superseded by part number: 86588450 |
| 48. | 2420Z1188 | [2] | GROMMET | KOB |
| 49. | 2416N3257 | [1] | STAND | STAND |
| 50. | 2416N3258 | [1] | STAND | KOB |
| 51. | 2414N1955 | [1] | COVER | KOB |
| 52. | 2414N1956 | [1] | COVER | COVER |
| 53. | 2414N1957 | [1] | COVER | KOB |
| 54. | 2414N1958 | [1] | COVER | KOB |
| 55. | 2416R233 | [1] | RUBBER MOUNTING | KOB |
| 61. | ZW26X12000 | [4] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| 70. | 2420T4505 | [18] | WASHER,7mm ID x 16mm OD x 1mm Thk | KOBID 07 x OD 16 x Th 1.0mm |
| 71. | 2418T17297 | [18] | SCREW | KOB |
| 72. | ZW22X06000 | [9] | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm, Start Serial: YG0647 | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm, Start Serial: YG0647 |
| . . | 2418T15636 | [18] | LOCK WASHER | KOB, Start Serial: YG0660 |
| 73. | 2414Z270D2 | [1] | CAP | KOB |
| 75. | 2419T3841D1 | [2] | PIN | KOB |
| 83. | 2416P8717 | [2] | BRACKET | KOB |
| 84. | 24100U157F1 | [1] | TANK | KOB Superseded by part number: YT54C00003F1 |
| 85. | ZS18C06016 | [2] | SCREW,Hex, M6 x 16mm | KOBM06x1.0x16mm |
| 86. | ZW26X06000 | [2] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 87. | 2432Z327 | [1] | PLATE | KOB |
| 89. | 24100J6136F4 | [1] | REMOTE-CONTROL ASSY, SEE FIGURE 03-002, Start Serial: YG0647 | |
| 90. | 24100N4066F1 | [1] | LEVER | KOBSEE FIGURE 03-004 |
| 91. | 2416N3340 | [1] | SUPPORT | |
| 92. | 2416J823 | [1] | SUPPORT | SUPPORT |
| 93. | ZS18C12065 | [4] | SCREW,Hex, M12 x 65mm | KOBM12x1.75x65mm |
| 94. | ZN17C10008 | [4] | NUT | KOBM10x1.50mm Superseded by part number: ZN18C10008 |
| 97. | 24100J6136F7 | [1] | REMOTE-CONTROL ASSY, SEE FIGURE 03-004, Start Serial: YG0660 | |
| 99. | 2416T13517 | [1] | BRACKET | KOB, Start Serial: YG0660 |
