| . . | 24100J6095F6 | [1] | HYDR LINES, UPP | |
| 1. | 2418T7002D6 | [1] | FLEXIBLE HOSE | KOB |
| 2. | ZC15X10500 | [4] | CLIP | KOB |
| 3. | 2418P9996 | [1] | TUBE | TUBE |
| 4. | ZD11G07500 | [1] | O-RING,74.40mm ID x 80.60mm OD x 3.10mm | KOBID 74.40 ± 0.65 x OD 80mm |
| 5. | ZS23C12035 | [4] | SCREW,Hex Socket Head, M12 x 35mm | KOBM12x1.75x35mm |
| 6. | ZW22K12000 | [4] | LOCK WASHER | KOBID 12.2 x OD 17.8 x Th 2.5mm |
| 7. | ZE13X12000 | [4] | CLAMP | KOBHalf -- (Incls. Capscrew & Lockwasher) |
| 8. | ZD12P02600 | [2] | O-RING | KOBID 25.70 ± 0.26 x OD 32mm |
| 9. | ZS13C10035 | [8] | SCREW | KOBM10x1.50x35mm Superseded by part number: ZS18C10035 |
| 10. | ZW22X10000 | [14] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 11. | 2444Z2287D1 | [1] | FLEXIBLE HOSE | KOB |
| 12. | 2418T12707 | [1] | TUBE | KOB |
| 13. | 2418T12398 | [1] | TUBE | TUBE |
| 14. | 2432T2245 | [4] | CLAMP | KOB |
| 15. | ZS13C12060 | [5] | SCREW | KOBM12x1.75x60mm Superseded by part number: ZS18C12060 |
| 16. | ZW22X12000 | [8] | LOCK WASHER | KOBID 12 x OD 21.5 x Th 3.0mm Superseded by part number: ZW26X12000 |
| 18. | 2420T4331D2 | [3] | SCREW,M12 x 1.75 x 160mm | KOBM12x1.75x160mm |
| 19. | ZN12C12010 | [3] | NUT | KOBM12x1.75mm Superseded by part number: ZN18C12010 |
| 20. | 2416N3207 | [1] | BRACKET | BRACKET |
| 21. | ZS13C16055 | [6] | SCREW | KOBM16x2.0x55mm |
| 22. | ZW22X16000 | [6] | WASHER, LOCK | KOBID 16 x OD 28.0 x Th 4.0mm |
| 23. | ZA23F28016 | [15] | CONNECTION | KOB1" PF - M36x1.50x49mm Long |
| 24. | ZD12P02900 | [16] | O-RING | KOBID 28.70 ± 0.29 x OD 35mm |
| 25. | ZA23F22012 | [3] | HYD CONNECTOR | KOB3/4"PF - M30x1.50 x 46mm Long |
| 26. | ZD12P02400 | [4] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 27. | 2444Z2320 | [1] | ELEC CONNECTOR | KOB1"PF-M30x1.50x48mm Long |
| 28. | ZA33F22012 | [1] | ELBOW | KOB |
| 29. | 2418P10031 | [1] | TUBE | TUBE |
| 30. | ZA23B28000 | [1] | CONNECTION | KOBM36x1.50x43mm Long |
| 31. | 2418T12237 | [1] | TUBE | TUBE |
| 32. | 2418P10030 | [1] | TUBE | TUBE |
| 33. | 2432T2244 | [2] | CLAMP | KOBDouble -- 102x32x12mm (Ø23xØ23mm) |
| 34. | ZS13C10050 | [2] | SCREW | KOBM10x1.50x50mm Superseded by part number: ZS18C10050 |
| 37. | 2418T12428 | [1] | TUBE | KOB |
| 38. | 2418T12427 | [1] | RIGID TUBE | KOB |
| 39. | 2416T13047 | [1] | ANGLE | ANGLE |
| 40. | 2432T2242 | [1] | CLAMP | KOBDouble -- 106x38x12mm (Ø23xØ29mm) |
| 41. | 2418T12372 | [2] | TUBE | TUBE |
| 42. | 2418T12371D1 | [1] | TUBE | TUBE |
| 43. | 2418T12371D2 | [1] | TUBE | TUBE |
| 44. | 2444Z2285D2 | [4] | FLEXIBLE HOSE | KOB |
| 45. | 2444Z2284D1 | [1] | FLEXIBLE HOSE | KOB |
| 46. | 2418T12157 | [1] | TUBE | TUBE |
| 47. | ZH32X12000 | [2] | 90 ELBOW,Male, 30 Degree Fl, PF 3/4" x PF 3/4", O-Ring | KOBElbow, 90° -- 3/4 PF (Incls. O-Ring 237-6012) |
| 48. | ZX22M12105 | [1] | HOSE,19.05mm ID x 1050mm L | KOB |
| 49. | 2418P11785 | [1] | TUBE | TUBE |
| 50. | ZD11G06000 | [1] | O-RING,59.40mm ID x 65.60mm OD x 3.10mm | KOBID 59.40 ± 0.61 x OD 65mm |
| 51. | ZS13C10030 | [4] | SCREW | KOBM10x1.50x30mm Superseded by part number: ZS18C10030 |
| 52. | 2444Z2323D1 | [1] | FLEXIBLE HOSE | KOB |
| 53. | R44P0089D8 | [1] | ELASTIC JOINT,101mm ID x 148.8mm OD x 165.1mm L | KOB |
| 53-3. | R44P0089D8S3 | [2] | GASKET | KOB |
| 54. | 2436R393S4 | [1] | VALVE | KOB |
| 55. | R44P0089D1 | [2] | COUPLING | KOB Superseded by part number: ZG15F03800 |
| 55-3. | R44P0089D1S3 | [2] | GASKET | KOB |
| 56. | 2418P11934 | [1] | TUBE | TUBE |
| 57. | 2420R367D53 | [1] | FLEXIBLE HOSE | KOB |
| 58. | ZC15X05000 | [4] | CLIP | KOB |
| 59. | 2418P11933 | [1] | TUBE | TUBE |
| 60. | 2420T2948D2 | [1] | U-BOLT | KOBM08x1.25x ID 38 x 72mm Long |
| 61. | ZN12C08007 | [9] | NUT | KOBM08x1.25mm Superseded by part number: 77278252, ZN18C08007 |
| 62. | 2432T878 | [3] | CLAMP | KOB |
| 63. | ZS13C08025 | [2] | SCREW | KOBM08x1.25x25mm Superseded by part number: ZS18C08025, 77276313 |
| 64. | ZW22X08000 | [2] | LOCK WASHER | KOBID 08 x OD 15.4 x Th 2.0mm Superseded by part number: 83990583 |
| 65. | R16T0152D2 | [6] | WASHER | KOBFlat -- ID 17 x OD 30 x Th 3.2mm |
| 68. | 2420T2948D4 | [1] | BOLT | KOBU-Bolt -- M08x1.25x ID 51 x 83.5mm Long |
| 69. | ZH21M08008 | [1] | HYD CONNECTOR | KOB |
| 70. | ZX15K08110 | [1] | KIT | KOB |
| 71. | ZH51M08008 | [1] | TEE | KOB |
| 72. | ZX15K08150 | [1] | TUBE | KOB |
| 74. | 2444Z2341D1 | [1] | FLEXIBLE HOSE | KOB |
| 77. | R44P0089D4 | [1] | COUPLING | KOB Superseded by part number: ZG15F05100 |
| 77-3. | R44P0089D4S3 | [2] | GASKET,50.85mm ID x 67.20mm OD | KOB |
| 93. | 2418P12311 | [1] | TUBE | |
| 94. | 2418T17456 | [1] | TUBE | |
| 95. | 2436U1261F1 | [1] | CONTROL VALVE | KOBVALVE, CONTROL |
