神钢零件查询(MD180LC) - EXCAVATOR ASN YG0647 (1/80-12/06) (05-007) - FILTER ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
122 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2446U234 | [1] | FILTER | KOB Superseded by part number: 2446U234F3 |
| 1. | 2446U234S1 | [1] | COVER | KOB |
| 2. | 2446U234S2 | [1] | CASE | KOB |
| 3. | 2446U234S3 | [1] | NUT | KOB |
| 4. | 2446U234S4 | [1] | PLATE | KOB |
| 5. | 2446U234S5 | [1] | SENSOR | KOBRING |
| 6. | 2446U234S6 | [1] | DRAIN PLUG | KOB Superseded by part number: 2446U180S100 |
| 7. | ZD11G07500 | [1] | O-RING,74.40mm ID x 80.60mm OD x 3.10mm | KOBID 74.40 ± 0.65 x OD 80mm |
| 8. | ZD11P01000 | [1] | O-RING | KOBID 9.8 ± 0.17 x OD 13.6mm |
| 9. | 2446U234S9 | [1] | GASKET | KOB |
| 10. | 2446U234S10 | [1] | DATA PLAQUE | KOBPLATE, CAUTION |
| 11. | 2446U234S11 | [1] | PACKING | KOBPLUG |
| 12. | 2446U234S12 | [1] | PLUG | KOB |
| 13. | 2446U234S13 | [2] | STRAINER ELEMENT | KOB |
| 14. | 2446U234S14 | [2] | SCREW | KOB Superseded by part number: 2446U180S10 |
| 15. | 2446U234S15 | [2] | FLEXIBLE JOINT | KOB Superseded by part number: 2446U234S18 |
| 16. | 2446U234S16 | [4] | GASKET | KOBCONNECTOR Superseded by part number: 2446U180S11 |
| 17. | 2446U234S17 | [1] | CUP | KOB Superseded by part number: 2446U180S13 |
