凯斯零件查询(2330) - PRECISION AIR CART (1/08-12/15) (44.250.02) - KIT CASTER WHEEL BEARING Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
561 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
B94632
|
[1] |
KIT
|
CAS
Incl 2 - 10
|
| 2. |
1013475
|
[1] |
WASHER
|
CAS
|
| 3. |
1020704
|
[1] |
SEAL
|
L
|
| 4. |
87505192
|
[1] |
HUB CAP
|
SAS
|
| 5. |
86900365
|
[1] |
BEARING CUP,82.96mm OD x 19.05mm W
|
WIN
|
| 6. |
86516462
|
[1] |
BEARING CUP,73.03mm OD x 19.05mm W
|
WIN
|
| 7. |
512725
|
[1] |
BEARING CONE,45.62mm ID x 25.4mm W
|
NH
|
| 8. |
86020752
|
[1] |
SLOTTED NUT
|
WIN
|
| 9. |
86516471
|
[1] |
BEARING CONE,34.92mm ID x 24.61mm W
|
BAS
|
| 10. |
87400
|
[1] |
COTTER PIN,3/16" x 2"
|
WIN
|
