纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-062[12]) - CAB INSTALLATION New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
193 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | LQ51C00003S004 | [1] | LOCK | KOBAssy. |
| 2. | LQ51C00003S006 | [1] | DOOR HANDLE | KOBAssy. |
| 3. | LQ51C00003S007 | [1] | HANDLE GRIP | KOB |
| 4. | LQ51C00003S008 | [1] | CLIP | KOB |
| 5. | LQ51C00003S012 | [1] | COVER | KOB |
| 6. | LQ51C00003S013 | [1] | COVER | KOB |
| 7. | LQ51C00003S021 | [2] | SCREW | KOB |
| 8. | LQ51C00003S022 | [2] | SCREW | KOB |
| 9. | LQ51C00003S024 | [3] | SET SCREW | KOB |
| 10. | LQ51C00003S026 | [3] | RIVET | KOB |
