纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-063[00]) - TANK ASSEMBLY, WASHER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
673 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT54C00006F1 | [1] | Washer | |
| 1. | YT54C00003F1 | [1] | TANK | KOBAssy., Water |
| 2. | YT54C00003S001 | [1] | ELECTRIC MOTOR | KOBAssy. |
| 3. | YT54C00003S002 | [1] | TANK | KOBAssy., Water |
| 4. | YT54C00003S003 | [1] | BRACKET | KOB Superseded by part number: 2416P7292 |
| 5. | YB54C01003P1 | [1] | BRACKET | KOB |
| 6. | ZM73C08016 | [2] | BOLT,M8x16mm - Course Thread | KOBSems |
| 7. | ZM73C06016 | [2] | BOLT,M6x16mm - Course Thread | KOBSems |
| 8. | YT02C01126D8 | [1] | TUBE | KOB Superseded by part number: YT02C01126D6 |
| 9. | YN03M01159P1 | [1] | GROMMET | KOB |
| 10. | YT02C01282P1 | [1] | ELEC CONNECTOR | KOB |
| 11. | PY01P01043D3 | [4] | CABLE TIE,188mm L | KOB |
| 12. | YN13E01375P1 | [3] | CLIP,M8 x 8.20mm Shank | KOB |
