纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-067[00]) - SEAT ASSEMBLY New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
422 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY25M00030F1 | [1] | | |
| 1. | YN25M00068F1 | [1] | SEAT | KOBAssy. Superseded by part number: 87516076 |
| 2. | YN25M00082F1 | [1] | SEAT | KOBInstal |
| 3. | ZW26K08000 | [4] | LOCK WASHER | KOB |
| 4. | ZS28C08020 | [4] | SCREW,Hex Socket Head, M8 x 20mm | KOB |
| 5. | YY11E00045F1 | [1] | | |
| 6. | YY11E01125P1 | [1] | WIRE HARNESS | KOB |
| 7. | PY01P01043D3 | [4] | CABLE TIE,188mm L | KOB |
| 8. | PY01P01043D5 | [5] | CABLE TIE,301mm L | KOB |
| 9. | PY01P01043DA | [1] | CABLE TIE,2.50mm W x 205mm L | KOB |
| 10. | YT11E01043P1 | [3] | SPRING | SM |
| 11. | YN13E01375P1 | [1] | CLIP,M8 x 8.20mm Shank | KOB |
