凯斯零件查询(2330) - PRECISION AIR CART (1/08-12/15) (55.301.02) - VARIABLE DRIVE BATTERY BOX/SWITCHES (2 TANK) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
430 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
80681
|
[4] |
LOCK NUT,5/16"
|
NH
Superseded by part number: 83990583
|
| 2. |
9635082
|
[4] |
NUT,5/16" - 18, Gr 5
|
NH
|
| 3. |
281010
|
[2] |
LOCK NUT,7/8"-14, GC
|
BAS
|
| 4. |
87872
|
[6] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
|
NH
|
| 5. |
86523851
|
[1] |
COTTER PIN,5/32" x 1 1/4"
|
WIN
|
| 6. |
4285
|
[2] |
WASHER
|
FLX
3/4" id 18ga Superseded by part number: 87326958
|
| 7. |
6854
|
[1] |
PIN
|
FLX
quick - 1/4" x 2 1/2" usable
|
| 8. |
51200136
|
[1] |
BATTERY BOX
|
FLX
with strap and lid Superseded by part number: ZQC120171001
|
| 8. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
The Battery Must Be 60 Amp, 12 Volt Automotive Type
|
| 9. |
9527
|
[1] |
WASHER
|
FLX
#10 ss
|
| 10. |
9966
|
[1] |
RELAY
|
FLX
electrical, 12 volt
|
| 11. |
84305559
|
[4] |
SCREW,Pan, #6 - 32 x 1/4"
|
SAS
machine #6-32 x 1/4"
|
| 12. |
412731A1
|
[1] |
CLAMP
|
FLX
cable, nylon
|
| 13. |
84307649
|
[1] |
SWITCH
|
SAS
Calibration Superseded by part number: 47739163
|
| 13A. |
87508155
|
[1] |
DECAL
|
SAS
Front Panel Calibration Switch
|
| 14. |
87641950
|
[2] |
SWITCH
|
SAS
meter on/off - NOTE IF SWITCH HAS INLINE FUSE ORDER PART NUMBER 13924 Superseded by part number: 47737283
|
| 15. |
51200085
|
[1] |
RIVET
|
FLX
pop 3/16" x 7/16"
|
| 16. |
GL-283
|
[1] |
TRAY
|
FLX
mount, battery - swivel
|
| 17. |
GL-604
|
[1] |
BRACKET
|
FLX
mount, multiple switch
|
