神钢零件查询(MD180LC) - EXCAVATOR ASN YG0647 (1/80-12/06) (09-002) - ARM ASSY, EXTENSION Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
242 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J6593F1 | [1] | ARM ASSY, EXTENSION | |
| 1. | 2411J2811F1 | [1] | ARM, EXTENSION | |
| 1-14. | 2405T1280 | [2] | BUSHING | KOB |
| 1-15. | B05T0041C2 | [2] | BUSHING | KOB |
| 1-16. | 2405T1297 | [2] | BUSHING | |
| 1-17. | 2405T936 | [2] | BUSHING | BUSHING |
| 1-18. | 2418T17578 | [1] | SPACER | KOB |
| 2. | 2406N807F1 | [1] | LINK | |
| 2-6. | 2405T674 | [1] | BUSHING | KOB |
| 2-7. | 2405T1285 | [2] | BUSHING | KOB |
| 3. | 2406P2707D1 | [1] | LINK, IDLER | LINK, IDLER |
| 4. | 2406P2707D2 | [1] | LINK, IDLER | LINK, IDLER |
| 5. | 2419P1566D4 | [2] | PIN | |
| 6. | 2419T4758 | [1] | PIN | PIN |
| 7. | 2411T1275 | [1] | COLLAR | COLLAR |
| 8. | 2420T4330D2 | [3] | SCREW,M16 x 2 x 150mm | KOBM16x2.0x150mm Superseded by part number: HS18C16150G1 |
| 9. | ZN12C16013 | [6] | NUT | KOBM16x2.0mm |
| 10. | 2445R372D7 | [2] | SEAL | KOB |
| 11. | 2445R138D6 | [8] | SEAL,70mm ID x 85.3mm OD x 4mm Thk | KOBSeal, Dust -- ID 70 x OD 85 x Th 4mm |
| 12. | ZG91S02000 | [4] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 13. | ZG91U02000 | [3] | LUBE NIPPLE | KOB90° x 1/8" PT |
