纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-080[03]) - AIR CONDITIONING New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
497 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | HX11W08210DX | [2] | FLEXIBLE HOSE | KOB |
| 2. | ZM73C10025 | [5] | BOLT,M10x25mm - Course Thread | KOBSems |
| 3. | ZC48X24014 | [1] | CLIP | KOB |
| 4. | PY01P01043D4 | [15] | CABLE TIE,4.80mm W x 251mm L | KOB |
| 5. | YT20M00021F1 | [1] | AIR CONDITIONER | KOBAssy. |
| 6. | YT20M00022F1 | [1] | AIR CONDITIONER | KOB Superseded by part number: YT20M00022F4 |
| 7. | YX91V00001F1 | [1] | COMPRESSOR,W/ Pulley | KOBAir |
| . . | YX91V00001F1R | [1] | REMAN-COMPRESSOR,W/ Pulley | KOBE80BMSR ASN LF06-04501 |
| . . | YX91V00001F1C | [1] | CORE-COMPRESSOR | KOBReturn Number |
| 8. | YT20M01215F1 | [1] | CONDENSER | KOB |
| 9. | YT96V00004F1 | [1] | EVAPORATOR | KOBDryer Assy., Air |
| 10. | YN13E01375P1 | [3] | CLIP,M8 x 8.20mm Shank | KOB |
| 11. | 2432R226D13 | [2] | CLIP | KOB |
| 12. | YT20M01161P1 | [1] | INSULATION | KOB |
| 13. | PY01P01043D6 | [2] | CABLE TIE,4.80mm W x 383mm L | KOB |
