凯斯零件查询(2330) - PRECISION AIR CART (1/08-12/15) (58.120.05) - AUGER - SMALL MESH SCREEN OPTION Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
781 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
86505867
|
[1] |
BOLT,Hex, 1/4" - 20 x 1", Gr 5
|
DUB
|
| 2. |
80701
|
[1] |
WASHER,0.31" ID x 0.73" OD x 0.07" Thk
|
NH
|
| 3. |
231-4144
|
[1] |
NUT,1/4"-20, GB
|
CAS
Superseded by part number: 280129
|
| 4. |
6854
|
[1] |
PIN
|
FLX
quick - 1/4" x 2 1/2" usable
|
| 5. |
84179842
|
[1] |
SHIELD
|
SAS
1 X 1, 10 INCH AUGER SCREEN
|
| 5. |
84209908
|
[1] |
SHIELD
|
SAS
1 X 1, 8 INCH AUGER SCREEN
|
| 6. |
84185671
|
[1] |
BRACKET
|
SAS
Auger Screen Lock
|
