纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-083[01]) - HARNESS ASSEMBLY, UPPER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
151 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | LF13E01056P1 | [1] | WIRE HARNESS | KOB Superseded by part number: LF13E01056P2 |
| 2. | YT13E01145P2 | [1] | ELECTRIC CABLE | KOB |
| 3. | YT13E01142P1 | [1] | ELECTRIC CABLE | KOB |
| 4. | YT13E01143P1 | [1] | ELECTRIC CABLE | KOB |
| 5. | YT13E01144P2 | [1] | ELECTRIC CABLE | KOB |
| 6. | LE13E01006P1 | [1] | HARNESS | KOBCable |
| 7. | EW02E01015D9 | [7] | CLIP,20mm ID, P Type | KOB |
| 8. | EW02E01015D4 | [2] | CLIP | KOB |
| 9. | PY01P01043D3 | [79] | CABLE TIE,188mm L | KOB |
| 10. | YN13E01375P1 | [37] | CLIP,M8 x 8.20mm Shank | KOB |
| 11. | ZC46X46014 | [2] | CLIP | KOB |
| 12. | ZM73C08016 | [13] | BOLT,M8x16mm - Course Thread | KOBSems |
| 13. | ZM73C10020 | [15] | BOLT,M10x20mm - Course Thread | KOBSems |
| 14. | EW02E01015D6 | [1] | CLIP | KOB |
| 15. | EW02E01015DF | [2] | CLIP | KOB |
