纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-083[05]) - HARNESS ASSEMBLY, UPPER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
784 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | EW02E01015DD | [2] | CLIP | KOB |
| 2. | EW02E01016D8 | [1] | CLIP | KOB |
| 3. | PY01P01043D3 | [79] | CABLE TIE,188mm L | KOB |
| 4. | PY01P01043D8 | [3] | CABLE TIE,102mm L | KOB |
| 5. | YN13E01375P1 | [37] | CLIP,M8 x 8.20mm Shank | KOB |
| 6. | ZN18C05004 | [1] | NUT | KOB |
| 7. | ZM73C10020 | [15] | BOLT,M10x20mm - Course Thread | KOBSems |
| 8. | ZW26X05000 | [2] | LOCK WASHER | KOBLock |
| 9. | ZS16C05012 | [2] | CAPTIVE WASHER SCREW | KOB |
| 10. | ZW16P05000 | [3] | WASHER | KOB |
