凯斯零件查询(2330) - PRECISION AIR CART (1/08-12/15) (75.100.05) - AIR PLENUM LEFT HAND Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
808 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87414
|
[3] |
LUBE NIPPLE,1/4" - 28
|
NH
|
| 2. |
9707580
|
[5] |
BOLT,Hex, 1/4" - 20 x 3/4", Gr 5, Full Thd
|
NH
|
| 3. |
280129
|
[5] |
NUT,1/4"-20
|
NH
|
| 4. |
9628503
|
[3] |
NUT,3/8"-16, G5
|
NH
|
| 6. |
459-11020
|
[4] |
SCREW,Slotted Pan Hd, #10-32 x 1 1/4"
|
CAS
|
| 7. |
8289
|
[2] |
WASHER
|
FLX
1/2" id 13/16" od 3/32"
|
| 8. |
87361
|
[3] |
WASHER,0.28" ID x 0.62" OD x 0.07" Thk
|
NH
|
| 9. |
9148
|
[4] |
LOCK NUT
|
FLX
#10-32, stainless steel
|
| 10. |
9704
|
[2] |
FLANGED BEARING,0.51" ID x 0.938" OD x 1.25"
|
FLX
support shaft air damper
|
| 11. |
51200063
|
[2] |
LINKAGE YOKE
|
FLX
clevis end 1/4" x 2"
|
| 12. |
87673
|
[1] |
COTTER PIN,1/8" x 1 3/4"
|
GI
|
| 13. |
88788
|
[2] |
COTTER PIN,3/32" x 1/2"
|
WIN
|
| 14. |
22152
|
[1] |
ROLL PIN
|
FLX
1/8" x 1"
|
| 15. |
22153
|
[2] |
CLEVIS PIN
|
FLX
1/4" x 3/4"
|
| 16. |
22172
|
[4] |
SEAL
|
FLX
3/4" od x 1/2" id x 1/8" w
|
| 17. |
22362
|
[1] |
SEAL
|
FLX
air plenum
|
| 18. |
22444
|
[4] |
SEALING WASHER
|
FLX
rolled nyltite sealing
|
| 19. |
161-116
|
[4] |
HEX SOC SCREW,Flat Hd, 1/4" - 20 x 1 1/2", SST
|
CAS
|
| 20. |
87486695
|
[1] |
PLENUM
|
SAS
meterbox LH
|
| 21. |
84173601
|
[1] |
STRAP
|
SAS
hold down RH
|
| 21. |
GL-491
|
[1] |
STRAP
|
FLX
hold down, right
|
| 22. |
84173602
|
[1] |
STRAP
|
SAS
hold down LH
|
| 22. |
GL-605
|
[1] |
STRAP
|
FLX
hold down, left
|
| 23. |
GL-661
|
[1] |
BRACKET
|
FLX
vane, left air plenum
|
| 24. |
GL-724
|
[1] |
GEAR
|
FLX
miter, air system Superseded by part number: 84365147
|
| 25. |
GL-741
|
[1] |
SHAFT
|
FLX
left air damper
|
| 26. |
GL-776
|
[1] |
BRACKET
|
FLX
bottom left air plenum
|
| 27. |
GL-777
|
[1] |
BRACKET
|
FLX
top - left air plenum
|
| 28. |
GL-801
|
[2] |
STRAP
|
FLX
cable sub hopper
|
| 29. |
GL-802
|
[1] |
STRAP
|
FLX
hose, sub hopper
|
| 30. |
GL-869
|
[1] |
ROD
|
FLX
control, air damper - threaded
|
| 31. |
GL-716A
|
[2] |
HALF BLADE
|
FLX
assembly, air damper
|
| 32. |
GM-423
|
[1] |
ARM
|
FLX
air damper control left
|
| 33. |
GM-361
|
[2] |
BRACKET
|
FLX
Air Plenum
|
| 34. |
21676
|
[1] |
RUBBER WASHER
|
SAS
1/4"id 5/8" 7/16"tk
|
