凯斯零件查询(2330) - PRECISION AIR CART (1/08-12/15) (75.100.07[02]) - AIR DAMPER LINKAGE (ASN YBS015201 - CURRENT) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
422 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84483295
|
[1] |
CONTROL LEVER
|
SAS
3 Tank, TBT, Incl 7
|
| 1. |
84483293
|
[1] |
LINKAGE
|
SAS
2 & 3 Tank Rear, 3 Tank Middle, Incl 7
|
| 1. |
84478429
|
[1] |
CONTROL LEVER
|
SAS
3 Tank Front, TBH, Incl 7
|
| 1. |
84466912
|
[1] |
HANDLE
|
SAS
2 Tank Front, TBT, Incl 7
|
| 1. |
84466916
|
[1] |
HANDLE
|
SAS
2 Tank Front, TBH, Incl 7
|
| 2. |
84466727
|
[1] |
ADJUSTING PLATE
|
SAS
3 Tank Front, TBT, Incl 7
|
| 3. |
84466095
|
[1] |
CONTROL LEVER
|
SAS
|
| 4. |
84478428
|
[1] |
LINKAGE
|
SAS
|
| 5. |
84483289
|
[1] |
LINKAGE
|
SAS
All Except 2 & 3 Tank Rear Models
|
| 5. |
84478696
|
[1] |
LINKAGE
|
SAS
2 & 3 Tank Rear Models Only
|
| 6. |
84466677
|
[1] |
CONTROL LEVER
|
SAS
|
| 7. |
84485649
|
[1] |
DECAL
|
SAS
Air Damper Control
|
| 8. |
GL-700.24
|
[1] |
DECAL
|
FLX
Control Pointer
|
| 9. |
280661
|
[1] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 2", Gr 5
|
GI
|
| 10. |
80702
|
[5] |
WASHER,0.44" ID x 1" OD x 0.08" Thk
|
NH
|
| 11. |
6909
|
[4] |
KNOB
|
FLX
|
| 12. |
88206
|
[2] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
NH
|
| 13. |
280206
|
[3] |
BOLT,Hex, 3/8" - 16 x 1 3/8", Gr 5
|
GI
Superseded by part number: 70927157
|
| 14. |
80680
|
[2] |
LOCK WASHER,3/8 0.381 CST ZND
|
NH
|
| 15. |
2335
|
[2] |
NUT,3/8"-16, G5
|
FLX
Superseded by part number: 280136
|
| 16. |
86521609
|
[3] |
FLANGE NUT,Flg, 3/8"-16
|
NH
|
| 17. |
280250
|
[2] |
COTTER PIN,3/32" OD x 3/4" L
|
NH
|
