| 1. |
80681
|
[1] |
LOCK NUT,5/16"
|
NH
Superseded by part number: 83990583
|
| 2. |
9635082
|
[2] |
NUT,5/16" - 18, Gr 5
|
NH
|
| 3. |
87670
|
[2] |
BOLT,1/2" - 13 x 1-1/4", Full Thd, Gr 5
|
NH
|
| 4. |
87689
|
[7] |
BOLT,1/2"-13 x 1.813" OAL, Gr 5
|
NH
|
| 5. |
280431
|
[4] |
NUT,1/2"-13, G5
|
NH
|
| 6. |
280374
|
[4] |
NUT,Hex, 5/8" - 11, Gr 5
|
NH
|
| 7. |
281010
|
[2] |
LOCK NUT,7/8"-14, GC
|
BAS
|
| 8. |
86992215
|
[2] |
LOCK NUT,1/2"-13, GC
|
GFD
|
| 9. |
80679
|
[4] |
LOCK WASHER,1/20.507 CST ZND
|
NH
|
| 10. |
12034871
|
[4] |
WASHER
|
ZED
5/8" Superseded by part number: 86729275
|
| 11. |
80700
|
[4] |
WASHER,0.56" ID x 1.38" OD x 0.11" Thk
|
NH
|
| 12. |
9635884
|
[2] |
BOLT,Hex, 5/16" - 18 1", Full Thd, Gr 5
|
NH
|
| 13. |
2245
|
[1] |
LINK,12.7mm Pitch
|
FLX
connector, offset 40-1
|
| 14. |
25195
|
[1] |
LINK,12.7mm Pitch
|
GI
roller conn 40-1
|
| 15. |
2259
|
[2] |
COLLAR
|
FLX
1" lock
|
| 16. |
86505999
|
[4] |
BOLT,Hex, 5/8" - 11 x 2", Gr 5
|
NH
|
| 17. |
88964
|
[1] |
BOLT,Hex, 5/16" - 18 x 4", Gr 5
|
PA
|
| 18. |
241-1326
|
[1] |
LINK,12.7mm Pitch
|
CAS
chain, connector 60-2 with clip
|
| 19. |
6565
|
[2] |
DECAL
|
FLX
grease 10 hours
|
| 20. |
7086
|
[2] |
BEARING ASSY,25.4mm ID
|
FLX
with 2-hole flange
|
| 21. |
GH-347
|
[1] |
SPROCKET
|
FLX
47 tooth
|
| 22. |
51200126
|
[1] |
SCREW
|
FLX
cap 1/2"-20 x 1 1/4" G8
|
| 23. |
9306
|
[1] |
SPROCKET
|
FLX
60w96
|
| 23. |
9308
|
[1] |
SPROCKET
|
FLX
dual wheel - 60w96
|
| 23. |
280156
|
[10] |
BOLT,Hex, 3/4" - 16 x 3 1/2", Gr 8
|
GI
|
| 23. |
87340
|
[10] |
LOCK WASHER,Helical Spring, 0.759" ID, CST, ZND
|
NH
|
| 23. |
9823966
|
[10] |
NUT,3/4"-16, G8
|
WIN
|
| 24. |
87424061
|
[1] |
KIT
|
SAS
magnetic clutch with lockout
|
| 25. |
87429222
|
[1] |
BRACKET
|
SAS
mount, inner mechanical drive
|
| 26. |
87429353
|
[1] |
BRACKET
|
SAS
mount, mechanical drive outer
|
| 27. |
GD-560
|
[2] |
KEY
|
FLX
1/4" sq x 1 1/2" long
|
| 28. |
GI-500.11
|
[1] |
DECAL
|
FLX
driven 1
|
| 29. |
GI-500.12
|
[1] |
DECAL
|
FLX
drive 2
|
| 30. |
GI-500.13
|
[1] |
DECAL
|
FLX
driven 2
|
| 31. |
GL-323
|
[1] |
PLATE
|
FLX
mounting bearing - outer wheel housing
|
| 32. |
GL-324
|
[1] |
BLOCK
|
FLX
bearing mounting plate, outer
|
| 33. |
GL-326
|
[1] |
CROSS SHAFT
|
FLX
meter drive axle
|
| 34. |
GL-360
|
[1] |
CHAIN (AG)
|
FLX
meter drive outer
|
| 35. |
GL-366
|
[1] |
CHAIN,Drive, 1828.8mm L
|
FLX
drive 96 tooth drive sprocket
|
| 36. |
GL-367
|
[1] |
SPROCKET
|
FLX
cross shaft - 60w23
|
| 37. |
GL-700.23
|
[1] |
WARNING DECAL
|
FLX
Rotating Parts
|
