纽荷兰零件查询(E80BMSR) - CRAWLER EXCAVATOR ASN LF05-04001 - (N8TA18060) (400-01-2[2]) - HYD LINES, LOW New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
634 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT02H00036F1 | [1] | Hyd Lines, Low | |
| A1. | YT02H01232D1 | [1] | FLEXIBLE HOSE | KOB |
| A2. | YT02H01232D2 | [3] | FLEXIBLE HOSE | KOB |
| A3. | ZX23M04135 | [1] | HOSE | KOB |
| A4. | ZX22M06135 | [1] | HOSE ASSY. | KOB |
| A5. | ZX23M04130 | [1] | HOSE | KOB |
| A6. | ZX22M06130 | [1] | HOSE | KOB |
| A7. | ZX56N08084 | [1] | FLEXIBLE HOSE | KOB |
| A8. | ZX56N08062 | [1] | FLEXIBLE HOSE | KOB |
| A9. | YT02H01237P1 | [1] | TUBE | KOB |
| A10. | YT02H01238P1 | [1] | TUBE | KOB |
| A11. | YT02H01243P1 | [2] | GROMMET | KOB |
| A12. | YT02H01234P1 | [2] | GROMMET | KOB |
| A13. | ZC26X15009 | [2] | CLAMP | KOB |
| A14. | ZW26X08000 | [2] | LOCK WASHER | KOBLock Superseded by part number: 83990583 |
| A15. | ZS18C08040 | [2] | SCREW,Hex, M8 x 40mm | KOBCap |
| A16. | PY01P01043D8 | [4] | CABLE TIE,102mm L | KOB |
| . . | YT19H00030F1 | [1] | Hyd Lines, Swivel | |
| B1. | HH25R08008G4 | [2] | HYD CONNECTOR | KOB |
| B2. | ZA23F15006 | [2] | HYD CONNECTOR | KOB |
| B3. | ZA33F18008 | [4] | ELBOW | KOB |
| B4. | 2444Z2336 | [1] | HYD CONNECTOR | KOBTee |
| B5. | 2444Z2359 | [1] | TEE | KOB |
| B6. | ZD12P01400 | [2] | O-RING | KOB |
| B7. | ZD12P01800 | [4] | O-RING | KOB |
| . . | YT12H00002F1 | [1] | Hyd Lines, Propel | |
| C1. | ZA23F18008 | [4] | HYD CONNECTOR | KOB |
| C2. | ZH22X06000 | [2] | HYD CONNECTOR | KOB |
| C3. | ZH22X04000 | [2] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB |
| C3-1. | ZD12P01100 | [1] | O-RING | KOB |
| . . | YT13H00006F1 | [1] | Hyd Lines, Cylinder | |
| D1. | ZA23H15006 | [2] | HYD CONNECTOR | KOB |
