神钢零件查询(MD200BLC) - EXCAVATOR ASN YQ0565 (1/80-12/06) (11-119) - CYLINDER ASSY (BOOM) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
466 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2438U997F1 | [1] | CYLINDER | KOBCONSISTS OF THE FOLLOWING PARTS Superseded by part number: 2438U1106F1 |
| 1. | 2438U996S1 | [1] | BARREL | KOB |
| 2. | 2438U624S4 | [1] | BUSHING | KOB |
| 3. | 2445R138D7 | [2] | SEAL,80mm ID x 95mm OD x 4mm Thk | KOBDust -- ID 80 x OD 95 x Th 4mm |
| 4. | 2438U996S4 | [1] | PISTON ROD | KOB |
| 5. | 2438U996S5 | [1] | BUSHING | KOB |
| 6. | 2438U941S3 | [2] | DUST CAP | KOB |
| 7. | 2438U996S7 | [1] | PISTON | KOB |
| 8. | ZD12G07500 | [1] | O-RING,74.40mm ID x 80.60mm OD x 3.10mm | KOBID 74.4mm x OD 77.5mm |
| 9. | ZD75G07500 | [2] | RING | KOB |
| 10. | 2438U980S8 | [1] | SEAL | KOB |
| 11. | 2438U914D1S10 | [2] | WEAR RING | KOB |
| 12. | 2438U996S12 | [2] | WEAR RING | KOB |
| 13. | 2438U995S11 | [1] | NUT | KOB |
| 14. | 2438U308S45 | [1] | LOCKING RING | KOB |
| 15. | 2438U996S15 | [1] | SPACER | KOBCUSHION |
| 16. | 2438U996S16 | [1] | COVER, ROD | COVER, ROD |
| 17. | 2438U1261S16 | [1] | BUSHING | KOB |
| 18. | 2438U278S24 | [1] | CLIP | KOB |
| 19. | ZD12P11500 | [2] | O-RING | KOBID 114.60 ± 0.94 x OD 125mm |
| 20. | 2438U914D1S16 | [2] | RING, BACK-UP | RING, BACK-UP |
| 21. | 2438U914D1S14 | [1] | O-RING | KOB |
| 22. | 2438U278S25 | [1] | RING | KOB Superseded by part number: R45P0050D3 |
| 23. | 45Z91D125 | [1] | O-RING | KOB |
| 24. | 2438U914D1S21 | [1] | PACKING | KOB Superseded by part number: 2438U307S35 |
| 25. | 2438U914D1S22 | [1] | SEAL, DUST | SEAL, DUST |
| 26. | ZS23C14055 | [12] | SCREW,Hex Socket Head, M14 x 55mm | KOBM14x2.0x55mm |
| 27. | 2438U996S27 | [1] | BRACKET | BRACKET |
| 28. | 2438U914D1S24 | [1] | U-BRACKET | KOB |
| 29. | ZS16C10030 | [2] | CAPSCREW | KOBSCREW M10x1.50x30mm Superseded by part number: ZS18C10030 |
| 30. | ZW26X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| . . | 2438U996R100 | [1] | REPAIR KIT | KOBREPAIR KIT, CONSISTS OF REF 19 - 25 Superseded by part number: 2438U996R100P |
| . . | 2438U996R200 | [1] | REPAIR KIT | KOBREPAIR KIT, CONSISTS OF REF 8 - 12 Superseded by part number: 2438U996R200P |
| . . | 2438U996R300 | [1] | CYLINDER | KOBREPAIR KIT, CONSISTS OF REF 1 - 26 Superseded by part number: 2438U1106F1 |
