神钢零件查询(MD200BLC) - EXCAVATOR ASN YQ0565 (1/80-12/06) (03-003) - REWORK, REMOTE CONTROL Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
403 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N6233F1 | [1] | REWORK, REMOTE CONTROL | |
| 1. | 2436R732F1 | [1] | SOLENOID VALVE | KOB |
| 2. | 2416P14902 | [1] | BRACKET | BRACKET |
| 3. | ZH32X06000 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring | KOBElbow, 90° -- (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 |
| 4. | ZH22X06000 | [2] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01400) |
| 5. | 2420R349D245 | [2] | HOSE | KOB2450mm Long (96-29/64 in) |
| 6. | 2420R349D175 | [1] | HOSE,6.35mm ID x 1750mm L | KOB |
| 7. | ZS23C06020 | [2] | SCREW,Hex Socket Head, M6 x 20mm | KOBM06x1.0x20mm Superseded by part number: ZS28C06020 |
| 8. | ZS13C10025 | [2] | CAPSCREW | KOBSCREW M10x1.50x25mm Superseded by part number: ZS18C10025 |
| 9. | ZN13C06005 | [2] | NUT | KOBM06x1.0mm Superseded by part number: ZN18C06005 |
| 10. | ZN13C10008 | [2] | NUT | KOBM10x1.50mm Superseded by part number: ZN18C10008 |
| 11. | ZW22X06000 | [2] | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm |
| 12. | ZW22X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 13. | 2479Z1894 | [1] | HARNESS | KOB |
| 14. | 2432Z290 | [5] | CLIP | KOBWire Ties -- 185mm Long Superseded by part number: PY01P01043D3 |
| 15. | 2420R349D195 | [1] | HOSE,6.35mm ID x 1950mm L | KOB1950mm Long (76-49/64 in) |
