| 1. |
87616668
|
[1] |
MANIFOLD
|
SAS
center 2 tank
|
| 2. |
80682
|
[8] |
LOCK WASHER,1/4"
|
PA
|
| 3. |
9707580
|
[16] |
BOLT,Hex, 1/4" - 20 x 3/4", Gr 5, Full Thd
|
NH
|
| 4. |
7770
|
[16] |
NUT,Hex, 1/4 - 20, Cl 5
|
NH
|
| 5. |
22577
|
[8] |
BOLT
|
FLX
1/4"-20 x 1 1/4", G5, all thread
|
| 6. |
448080A1
|
[8] |
VALVE
|
SAS
single / double shoot
|
| 8. |
GD-602
|
[8] |
HOSE,2.50" ID x 2.25"
|
FLX
|
| 9. |
86050197
|
[64] |
HOSE CLAMP,58.6mm - 82.5mm, Worm Gear
|
FOR
|
| 10. |
GL-452
|
[8] |
HOSE,2.50" ID x 6.44"
|
FLX
|
| 11. |
GL-443
|
[2] |
MANIFOLD
|
FLX
outlet
|
| 12. |
80701
|
[24] |
WASHER,0.31" ID x 0.73" OD x 0.07" Thk
|
NH
|
| 13. |
280129
|
[8] |
NUT,1/4"-20
|
NH
|
| 14. |
4731
|
[8] |
CAP
|
FLX
vinyl 2 1/2" id x 1" long
|
| 15. |
8275
|
[2] |
PIN,3/4" - 10 x 9.75"
|
FLX
pin locator, center manifold
|
| 16. |
84972
|
[4] |
JAM NUT,Jam, 3/4"-10, G2
|
NH
|
| 17. |
22409
|
[2] |
DECAL
|
FLX
center manifold cleanout
|
| 18. |
GL-700.21
|
[2] |
CAUTION DECAL
|
FLX
keep hands
|
| 19. |
GL-700.22
|
[1] |
DECAL
|
FLX
two outlet valve a
|
| 20. |
GL-444
|
[2] |
CARRIER
|
FLX
center manifold
|
| 21. |
21319
|
[8] |
BOLT
|
FLX
5/16"-18 x 1" ss hx-skt
|
| 22. |
9586
|
[8] |
FLANGE NUT
|
FLX
flange 5/16" serrated
|
| 23. |
GL-460
|
[4] |
SPACER
|
FLX
tube mount
|
| 24. |
425043A1
|
[2] |
TUBE
|
FLX
storage & cap, 17 3/16"
|
| 25. |
80664
|
[4] |
WASHER,0.38" ID x 0.88" OD x 0.08" Thk
|
NH
|
| 26. |
88964
|
[2] |
BOLT,Hex, 5/16" - 18 x 4", Gr 5
|
PA
|
| 27. |
80681
|
[2] |
LOCK NUT,5/16"
|
NH
Superseded by part number: 83990583
|
| 28. |
9635082
|
[2] |
NUT,5/16" - 18, Gr 5
|
NH
|
| 29. |
425090A1
|
[2] |
PLASTIC-BAG
|
FLX
collector with clasp
|
| 30. |
412785A1
|
[1] |
SCALE
|
FLX
hanging weight Superseded by part number: 47486597
|
| 31. |
GD-388
|
[2] |
CHAIN
|
SAS
safety, inlet shield - 9"
|
| 32. |
412750A1
|
[2] |
SCREW,Sl, #8 - 32 x 3/4"
|
FLX
mch #8-32 x 3/4" ph sq-slt
|
| 33. |
280299
|
[4] |
WASHER,0.19" ID x 0.44" OD x 0.05" Thk
|
NH
|
| 34. |
87653
|
[4] |
NUT,#8-32
|
WIN
Superseded by part number: 86977693
|
| 35. |
80755
|
[2] |
COTTER PIN,1/8" OD x 1" L
|
NH
|
| 36. |
GL-700.44
|
[1] |
DECAL
|
FLX
two outlet valve b
|
| 37. |
9475
|
[16] |
TUBE
|
FLX
manifold transition, velocity sensor
|
| 38. |
425095A1
|
[16] |
PLUG
|
FLX
manifold transition - velocity sensor
|
| 39. |
GL-116
|
[2] |
SPACER
|
FLX
plate transition manifold rear
|
| 40. |
GL-442
|
[1] |
PANEL
|
FLX
mount, transition manifold
|
| 41. |
7187
|
[1] |
PLUG
|
FLX
manifold transition
|
