凯斯零件查询(2330) - PRECISION AIR CART (1/08-12/15) (80.180.AU[05]) - DELUXE AUGER TRANSPORTING LOCK Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
174 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47418302
|
[1] |
LATCH
|
SAS
Bracket Lock Black
|
| 2. |
47401625
|
[1] |
LATCH
|
SAS
Transport Lock Black
|
| 3. |
47418306
|
[1] |
LOCKING HANDLE
|
SAS
Transport Black
|
| 4. |
432577A1
|
[1] |
HITCH PIN,12.7mm OD x 127mm L
|
FLX
.5 X 3.5
|
| 5. |
88557
|
[2] |
BOLT,Hex, 3/4" - 10 x 2", Gr 5, Full Thd
|
BEL
|
| 6. |
9626598
|
[2] |
NUT,3/4"-10, GB
|
PA
Superseded by part number: 280375
|
