凯斯零件查询(2330) - PRECISION AIR CART (1/08-12/15) (88.470.03) - KIT SCISSOR LIFT PARTIAL Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
205 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47487299
|
[1] |
KIT
|
MKT
Incl 2 - 11
|
| 2. |
GL-644
|
[1] |
BRACKET, PIVOT
|
FLX
UPPER
|
| 3. |
GL-645V2
|
[1] |
BRACKET
|
FLX
LOWER
|
| 4. |
GL-793
|
[2] |
BUSHING
|
FLX
|
| 5. |
86632583
|
[2] |
WASHER,1.28" ID x 2" OD x 0.12" Thk
|
FOR
|
| 6. |
80299
|
[4] |
WASHER,0.69" ID x 1.75" OD x 0.13" Thk
|
NH
|
| 7. |
87338
|
[2] |
BOLT,Hex, 5/8" - 11 x 3", Gr 5
|
NH
|
| 8. |
6395
|
[2] |
LOCK NUT,5/8"-11, GB
|
FLX
|
| 9. |
84307616
|
[1] |
CLAMP
|
SAS
|
| 10. |
9637692
|
[1] |
NUT,3/8"-16, GB
|
NH
|
| 11. |
9450
|
[1] |
HYDRAULIC CYLINDER,Double Acting, 28.57mm Rod, 254mm Stroke
|
FLX
|
