凯斯零件查询(2355) - PRECISION AIR CART (11/15-) (27.550.AJ[01]) - NARROW REAR AXLE WITH SINGLE TIRES Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
324 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47561066
|
[2] |
HOUSING
|
SAS
Rear Axle, Single PTD
|
| 2. |
47459894
|
[2] |
HUB
|
SAS
Spindle
|
| 3. |
47456794
|
[1] |
FRAME
|
SAS
Rear Axle
|
| 4. |
47537365
|
[1] |
STRUT
|
SAS
LH Axle Brace
|
| 5. |
47537368
|
[1] |
STRUT
|
SAS
RH Axle Brace
|
| 6. |
382101
|
[28] |
BOLT,Hex, M20 x 2.5 x 80mm, Cl 8.8
|
NH
|
| 7. |
412346
|
[4] |
BOLT,Hex, M20 x 2.5 x 90mm, Cl 8.8
|
NH
|
| 8. |
725637
|
[34] |
NUT,M20 x 2.5, Cl 8
|
BER
Superseded by part number: 380424
|
| 9. |
380422
|
[2] |
BOLT,Hex, M20 x 2.5 x 190mm, Cl 8.8
|
NH
|
