纽荷兰零件查询(E80BMSR) - CRAWLER EXCAVATOR ASN LF05-04001 - (N8TA18060) (B118M-41A) - FUEL FILTER AND BRACKET New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
959 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1A. | VI8944150773 | [1] | FILTER ASSY | KOBFuel Superseded by part number: VI8970142041 |
| 1B. | VI8973112542 | [1] | FILTER ASSY | KOBFuel |
| 2A. | VI8971725491 | [1] | ELEMENT | KOBKit, Fuel Filter Superseded by part number: YB02P00001-2 |
| 2B. | VI8972133810 | [1] | ELEMENT | KOBKit, Fuel |
| 5. | VI9992023140 | [1] | PLUG | KOBBolt, Fuel Filter |
| 6A. | VI8973089880 | [2] | GASKET | KOBFuel Filter |
| 6B. | VI9095720140 | [1] | PACKING | KOBGasket, Fuel Filter |
| 8. | VI8941329480 | [1] | BODY | KOBCover, Fuel Filter |
| 11. | VI8941551830 | [1] | GASKET | KOBCase To Body, Fuel Filter |
| 17. | VI8972891250 | [1] | Float, Fuel Filter | |
| 20. | VI8941483900 | [2] | JOINT | KOBEye, Fuel Filter |
| 66. | VI8972891330 | [1] | GASKET | KOBPlug, Fuel Filter |
| 69. | VI9099063251 | [2] | BOLT | KOBEye, Fuel Filter Superseded by part number: 87596570 |
| 77. | VI8972891360 | [1] | Hose, Fuel Filter | |
| 79. | VI8972891310 | [1] | Ring, Body To Case | |
| 105. | VI8972891180 | [1] | OIL SEPARATOR | KOBCase, Fuel Filter |
| 119. | VI8972891320 | [1] | PLUG | KOBDrain, Fuel Filter |
