神钢零件查询(MD200BLC) - EXCAVATOR ASN YQ0565 (1/80-12/06) (07-002) - ARM ASSY, 2.94M Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
657 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J10794F1 | [1] | ARM ASSY, 2.94M | |
| 1. | 2411J3531F1 | [1] | ARM | ARM |
| 1-21. | 2405T1274 | [2] | BUSHING,80mm ID x 95mm OD x 93mm L | KOB Superseded by part number: 2405T1902 |
| 1-22. | B05T0041C2 | [2] | BUSHING | KOB |
| 1-23. | B05T0009C2 | [2] | BUSHING | KOB |
| 1-24. | 2418T17497 | [1] | SPACER | KOB |
| 1-25. | 2418T17498 | [1] | SPACER | KOB |
| 2. | 2438U995F1 | [1] | CYLINDER, BUCKET | CYLINDER, BUCKET |
| 3. | 2406N619F1 | [1] | LINK, BUCKET | |
| 3-1. | 2405T951 | [2] | BUSHING | KOB |
| 3-2. | 2405T1275 | [2] | BUSHING | KOB |
| 4. | 2406P3913D1 | [1] | LINK CONROD | KOB |
| 5. | 2406P3913D2 | [1] | LINK CONROD | KOB |
| 6. | 2419P2952 | [1] | PIN | KOB Superseded by part number: 2419P4040 |
| 7. | 2419P2951 | [1] | PIN | KOB |
| 8. | 2419P1710D1 | [1] | PIN | KOB |
| 9. | 2419T3752 | [2] | PIN | KOB Superseded by part number: 2419T7605D1 |
| 10. | 2419P1566D1 | [1] | PIN | KOB |
| 11. | 2418T12144 | [1] | RIGID TUBE | KOB |
| 12. | 2418T17376 | [1] | RIGID TUBE | KOB |
| 13. | ZX56N12135 | [2] | FLEXIBLE HOSE | KOB Superseded by part number: ZX56T12135 |
| 14. | 2445R372D1 | [2] | DUST CAP | KOB |
| 15. | 2445R372D2 | [10] | DUST CAP | KOB |
| 16. | ZG91S02000 | [6] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 17. | ZG91U02000 | [1] | LUBE NIPPLE | KOB90° x 1/8" PT |
| 18. | ZD12P02600 | [2] | O-RING | KOBID 25.70 ± 0.26 x OD 32mm |
| 19. | ZS13C16130 | [1] | SCREW | KOB |
| 20. | 2420T4330D21 | [1] | CAPSCREW | |
| 21. | ZS13C10070 | [8] | SCREW | KOBM10x1.50x70mm Superseded by part number: ZS18C10070 |
| 22. | ZS13C16140 | [2] | SCREW | KOBM16x2.0x140mm |
| 23. | ZS13C10050 | [1] | SCREW | KOBM10x1.50x50mm Superseded by part number: ZS18C10050 |
| 24. | ZN13C16013 | [8] | NUT | KOBM16x2.0mm |
| 25. | ZW22X10000 | [9] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 26. | 2432T1187 | [1] | CLAMP | KOB Superseded by part number: YN43H01097P1 |
| 27. | 2420R349D086 | [1] | HOSE | KOBBOSS Superseded by part number: HX21E04086DX |
| 28. | 2418T19206D1 | [2] | RING | KOB |
| 29. | 2419T6002D1 | [2] | PIN,16mm OD x 115mm L | KOBOD 16 x 115mm Long |
| 30. | ZH32Z04000 | [1] | ELBOW | KOB90° -- (1/4" PT - 1/4" PT), (Incls. O-Ring ZD12P01100) |
| 31. | ZC45X10009 | [1] | CLIP | KOB Superseded by part number: ZC46X10009 |
| 32. | ZN13C06005 | [1] | NUT | KOBM06x1.0mm Superseded by part number: ZN18C06005 |
| 33. | ZW22X06000 | [1] | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm |
| 34. | 2444Z2002 | [1] | HYD CONNECTOR | KOB1/8"PTx1/4"PFx32mm Long |
| 35. | B16T0442D2 | [2] | SHIM,130mm OD x 72mm ID x 1.6mm Thk | KOBID 72 x OD 130 x Th 1.6mm |
| 36. | B16T0442D4 | [4] | SHIM,82mm ID x 150mm OD x 1.6mm Thk | KOBID 82 x OD 150 x Th 1.6mm |
| 37. | B16T0442D37 | [1] | SHIM,155mm OD x 87mm ID x 1.6mm Thk | KOBID 87 x OD 155 x Th 1.6mm |
