凯斯零件查询(2355) - PRECISION AIR CART (11/15-) (35.525.AE[01]) - 435, 460, 580 BUSHEL, HYDRAULIC AUGER CONTROL VALVE Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
144 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84583850
|
[1] |
HYDRAULIC VALVE
|
SAS
Deluxe Auger Control, Incl 2 - 16
|
| 2. |
47429780
|
[1] |
BODY
|
SAS
|
| 3. |
47429763
|
[1] |
SPOOL
|
SAS
|
| 4. |
NSS
|
[2] |
NOT SOLD SEPARAT
|
CON
O-Ring, Incl in 1
|
| 6. |
47429770
|
[1] |
CAP
|
SAS
Detent
|
| 8. |
47429772
|
[1] |
COMPRESSION SPRING
|
SAS
|
| 9. |
47429774
|
[1] |
BALL
|
SAS
Steel
|
| 10. |
87406
|
[2] |
LOCK PIN,6.35mm OD x 38.1mm L, Slotted
|
WIN
|
| 11. |
87035062
|
[9] |
PLUG,Hex, 1/2"-20 ORB
|
BRR
Incl 12
|
| 12. |
129270
|
[9] |
O-RING,0.072" Thk x 0.414" ID, -905, Cl 6, 90 Duro
|
NH
|
| 14. |
322896
|
[2] |
HYD CONNECTOR,1-1/16" - 12 ORB x 1-1/16" - 12 JIC
|
BHB
Incl 15
|
| 15. |
167266
|
[2] |
O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro
|
NH
|
| 16. |
330344
|
[2] |
45 ELBOW,1-1/16" - 12 JIC x 1-1/16" - 12 ORB
|
WIN
Incl 15
|
| 17. |
47429777
|
[1] |
SERVICE KIT
|
SAS
Used on 1
|
