纽荷兰零件查询(E80BMSR) - CRAWLER EXCAVATOR ASN LF05-04001 - (N8TA18060) (B118M-65[2]) - STARTER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
308 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | VI8980723151 | [1] | STARTER MOTOR | KOBAsm |
| . . | VI8980741250 | [1] | | SMCase Pinion, Starter |
| . . | VI8971164820 | [1] | CLUTCH | KOBAsm Pinion, Starter |
| . . | VI8971164850 | [1] | GEAR | KOBBracket Center Starter |
| . . | VI8971164810 | [1] | BEARING | KOBGear Shaft Starter |
| . . | VI8971164830 | [1] | SHAFT | KOBGear Starter |
| . . | VI8971164840 | [1] | WASHER | KOBGear Shaft Starter |
| . . | VI8980741270 | [1] | | SMYoke Starter |
| . . | VI8972312800 | [1] | ARMATURE | KOBStarter |
| . . | VI1811298370 | [1] | BEARING | KOBArmature, Starter |
| . . | VI8971164890 | [1] | WASHER | KOBThrust, Armature, Starter |
| . . | VI8971165160 | [4] | SPRING | KOBBrush Holder Starter |
| . . | VI8971165110 | [1] | HOLDER | KOBBrush Starter |
| . . | VI8972109170 | [1] | COVER | KOBRr Cover Starter |
| A. | VI8971165140 | [1] | SCREW | KOBBolt Through, Starter |
| B. | VI8971164950 | [1] | BOLT | KOBThrough, Starter |
| . . | VI8971164920 | [1] | LEVER | KOBShift, Starter |
| . . | VI8971164940 | [1] | SWITCH | KOBEngage Starter |
| . . | VI8971164900 | [4] | BRACKET | KOBGear Clu Starter |
| . . | VI8971165150 | [1] | BALL | KOBPinion, Starter |
| . . | VI8971164880 | [1] | CLUTCH | KOBPinion, Starter |
| . . | VI8980743160 | [1] | GEAR | SMPinion Clu, Starter |
| . . | VI8944756880 | [1] | STOP | KOBSet Pinion |
| . . | VI8971165100 | [2] | BRUSH | KOBAsm Starter |
