纽荷兰零件查询(E80BMSR) - CRAWLER EXCAVATOR ASN LF05-04001 - (N8TA18060) (HC161[1]) - VALVE ASSY, CONTROL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
742 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT30V00042F1 | [1] | Valve Assy, Control | |
| . . | YT30V00042F2 | [1] | CONTROL BLOCK | KOBValve Assy Superseded by part number: YT30V00042F4 |
| 2. | NSS | [1] | NOT SERVICED SEPARATELY | CONPlunger (For F1 ONLY) |
| 4. | PY30V00001S026 | [2] | O-RING | KOBO-ring |
| 5. | YT30V00039S004 | [1] | COVER | KOB |
| 6. | YT30V00039S071 | [1] | CAP | KOB |
| 7. | YT30V00039S070 | [1] | SPACER | KOB |
| 8. | YT30V00039S072 | [1] | SPACER | KOB |
| 9. | PY30V00001S028 | [1] | SPRING | KOBSpring |
| 10. | YT30V00039S068 | [1] | GUIDE | KOB |
| 11. | YT30V00039S033 | [1] | CAP | KOB |
| 12. | YT30V00039S024 | [2] | O-RING | KOB |
| 13. | 2436U1309S29 | [1] | CAP | KOB |
| 14. | ZD12P00800 | [2] | O-RING,1.9mm Thk x 7.8mm ID, 90 Duro | KOB |
| 15. | YT30V00039S035 | [1] | SPOOL | KOB |
| 16. | YT30V00039S089 | [1] | PLUG | KOB |
| 17. | YT30V00039S037 | [1] | SPRING | KOB |
| 19. | ZD12P01800 | [5] | O-RING | KOB |
| 22. | YW30V00001S155 | [1] | PLUG | KOBCap |
| 23. | YT30V00039S003 | [1] | COVER | KOB |
| 24. | YT22V00012S004 | [1] | PLUG | KOB |
| 25. | YT30V00039S045 | [1] | POPPET | KOB |
| 26. | YT30V00039S044 | [1] | SPRING | KOB |
| 27. | YT30V00042S027 | [1] | Cover | |
| 28. | 2436U1514S38 | [1] | O-RING | KOBO-ring |
| 29. | ZS23C08060 | [4] | SCREW,Hex Socket Head, M8 x 60mm | KOBCap |
| 30. | ZS28C06020 | [4] | SCREW,Hex Socket Head, M6 x 20mm | KOBCap |
| 31. | ZD12P01000 | [2] | O-RING | KOB |
| 32. | ZD12P02200 | [1] | O-RING | KOB |
| 33. | YT30V00039S023 | [1] | CAP | KOB |
| 34. | 2436U2716S20 | [1] | SPRING | KOB |
| 35. | YT30V00039S026 | [1] | CHECK CONTROL | KOB |
