纽荷兰零件查询(E80BMSR) - CRAWLER EXCAVATOR ASN LF05-04001 - (N8TA18060) (HC310[1]) - REDUCTION ASSY (SWING) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
301 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT32W00006F1 | [1] | REDUCER | KOBAssy (swing) |
| 1. | YR32W00002S001 | [1] | SHAFT | KOBPinion |
| 2. | YR32W00002S002 | [1] | COLLAR | KOB |
| 3. | YR32W00002S003 | [1] | PLATE | KOB |
| 4. | YR32W00002S004 | [1] | BEARING | KOBRoller |
| 5. | YT32W00006S005 | [1] | MOTOR HOUSING | KOBCase, Gear |
| 6. | YT32W00002S006 | [1] | PLUG | KOB |
| 7. | YR32W00002S007 | [1] | SEAL | KOBOil |
| 8. | YR32W00002S008 | [1] | BEARING | KOBRoller |
| 9. | PY32W00001S019 | [2] | PIN | KOB |
| 10. | YR32W00002S010 | [1] | GEAR | KOBRing |
| 11. | YR32W00002S011 | [1] | GEAR | KOB |
| 12. | YR32W00002S012 | [1] | GEAR | KOBSun |
| 13. | NSS | [1] | NOT SERVICED SEPARATELY | CONHolder Assy |
| 14. | YR32W00002S014 | [6] | CAPSCREW | KOBSCREW Cap |
| 22. | YR32W00002S016 | [2] | COLLAR | KOB |
| 23. | YT32W00006S023 | [1] | NIPPLE | KOB |
| . . | YT32W00002R100 | [1] | REPAIR KIT | KOBConsists Of Item 16x6, 17x3, 18x3 |
