神钢零件查询(MD200BLC) - EXCAVATOR ASN YQU0001 (1/80-12/06) (11-008) - VALVE ASSY, SOLENOID - 2436U1240F1, F2, F3 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
282 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2436U1240F1 | [1] | SOLENOID VALVE | KOBASSY, CONSISTS OF THE FOLLOWING PARTS |
| . . | 2436U1240F2 | [1] | VALVE ASSY, SOLENOID CONSISTS OF THE FOLLOWING PARTS | VALVE ASSY, SOLENOID CONSISTS OF THE FOLLOWING PARTS |
| . . | 2436U1240F3 | [1] | VALVE ASSY, SOLENOID CONSISTS OF THE FOLLOWING PARTS | VALVE ASSY, SOLENOID CONSISTS OF THE FOLLOWING PARTS |
| 1. | 2436U1240S1 | [1] | HOUSING | |
| 2. | ZD12P01500 | [6] | O-RING | KOBID 14.80 ± 0.20 x OD 19mm |
| 4. | 2436U1240S4 | [1] | SPOOL | KOBF1 ONLY |
| 5. | 2436U1240S5 | [2] | SPOOL F1, F3 ONLY | SPOOL F1, F3 ONLY |
| 6. | 2436R688S321 | [3] | SPRING | SPRING |
| 7. | 2436U1159S7 | [1] | COVER | |
| 8. | ZS23C04010 | [8] | SCREW,Hex Socket Head, M4 x 10mm | KOBM04x0.7x10mm |
| 9. | 2436U1159S9 | [3] | SOLENOID VALVE | KOB |
| 10. | NSS | [1] | NOT SOLD SEPARAT | CONNAME-PLATE |
| 11. | 2436U1170S14 | [2] | PIN | KOBPIN |
| 12. | 2436U1240S12 | [1] | SPOOL F3 ONLY | SPOOL F3 ONLY |
