神钢零件查询(MD200BLC) - EXCAVATOR ASN YQU0001 (1/80-12/06) (11-020) - CYLINDER ASSY (BUCKET) - 2438U995F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
173 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2438U995F1 | [1] | CYLINDER, BUCKET ASSY, CONSISTS OF THE FOLLOWING PARTS | CYLINDER, BUCKET ASSY, CONSISTS OF THE FOLLOWING PARTS |
| 1. | 2438U995S1 | [1] | BARREL | KOB |
| 2. | 2438U624S4 | [2] | BUSHING | KOB |
| 3. | 2438U568S31 | [4] | DUST CAP | KOB Superseded by part number: 2445R138D7 |
| 4. | 2438U995S4 | [1] | PISTON ROD | KOB |
| 5. | 2438U995S5 | [1] | PISTON | KOB |
| 6. | ZD12G08000 | [1] | O-RING,79.40mm ID x 85.60mm OD x 3.10mm | KOBID 79.40 ± 0.69 x OD 85mm |
| 7. | ZD75G08000 | [2] | BACK-UP RING | KOB |
| 8. | 2438U995S8 | [1] | WIPER SEAL | KOB |
| 9. | 2438U783S6 | [2] | RING, WEAR | RING, WEAR |
| 10. | 2438U995S10 | [2] | WEAR RING | KOB |
| 11. | 2438U995S11 | [1] | NUT | KOB |
| 12. | 2438U308S45 | [1] | LOCKING RING | KOB |
| 13. | 2438U995S13 | [1] | COVER | KOB |
| 14. | 2438U1310S16 | [1] | BUSHING | KOBBUSHING Superseded by part number: 2405U104D080060 |
| 15. | 2438U718S22 | [1] | CLIP | KOB |
| 16. | ZD12P11000 | [1] | O-RING | KOB |
| 17. | 2438U915S13 | [1] | RING | KOBRING, BACK-UP Superseded by part number: 2445R216D12 |
| 18. | 2429U71S19 | [1] | O-RING | KOB |
| 19. | R45P0050D9 | [1] | RUBBER SEAL | KOB |
| 20. | R45P0051D18 | [1] | O-RING | O-RING |
| 21. | 2418U130D34 | [1] | PACKING | KOBROD Superseded by part number: Y0496604500 |
| 22. | 2438U928S24 | [1] | DUST CAP | KOB Superseded by part number: 2438U928S33 |
| 23. | 2438U995S23 | [12] | SCREW | KOB |
| 24. | 2438U995S24 | [1] | U-BRACKET | KOB |
| 25. | 2438U915S22 | [1] | BAND | KOB |
| 26. | ZS16C10030 | [2] | CAPSCREW | KOBSCREW M10x1.50x30mm Superseded by part number: ZS18C10030 |
| 27. | ZW26X10000 | [1] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 28. | ZE82T02000 | [1] | PLUG | KOBPipe, 1.25" PT |
| . . | 2438U995R100 | [1] | REPAIR KIT | KOBREPAIR Superseded by part number: 2438U995R100P |
| . . | 2438U995R200 | [1] | REPAIR KIT | KOBREPAIR Superseded by part number: 2438U995R200P |
