凯斯零件查询(2355) - PRECISION AIR CART (11/15-) (55.516.AA[08]) - BRAKE SWITCH WIRE HARNESS Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
281 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47950269
|
[1] |
WIRE HARNESS
|
SAS
Brake Switch Incl 2 - 4
|
| 2. |
87697541
|
[1] |
ELEC CONNECTOR
|
MKT
Brake Switch
|
| 2. |
87693329
|
[2] |
TERMINAL
|
CAS
Tin
|
| 2. |
87705061
|
[1] |
RETAINER
|
BN
Lock
|
| 3. |
87697542
|
[1] |
WIRE CONNECTOR
|
SAS
Brake Switch
|
| 3. |
87693269
|
[2] |
ELEC. TERMINAL PIN
|
GI
Tin
|
| 3. |
87693314
|
[1] |
LOCK
|
SAS
Gray Secondary
|
| 4. |
87693744
|
[1] |
WIRE CONNECTOR
|
RAC
Brake Switch Signal Superseded by part number: 245480C1
|
| 4. |
87692883
|
[1] |
CABLE TERMINAL
|
BAS
Tin
|
| 4. |
87686742
|
[1] |
PLUG
|
MKT
Green Cavity Seal
|
