纽荷兰零件查询(E80BMSR) - CRAWLER EXCAVATOR ASN LF05-04001 - (N8TA18060) (110-01[1]) - HYD LINES, RETURN New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
848 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LF32H00003F1 | [1] | Hyd Lines, Return | |
| . . | LF32H00005F1 | [1] | PIPE | KOBHyd Lines, Return |
| 1. | 2436R576F5 | [1] | CHECK VALVE | KOBAssy |
| 2. | YT32H01103P1 | [1] | TUBE | KOB |
| 3. | YT32H01102D3 | [2] | FLEXIBLE HOSE | KOB |
| 4. | YT32H01102D4 | [1] | FLEXIBLE HOSE | KOB |
| 5. | YT32H01105P1 | [1] | TUBE | KOB |
| 6. | ZX32M06038 | [1] | HOSE ASSY. | KOBHose Assy Superseded by part number: ZX32M06040 |
| 7. | ZX22M06082 | [1] | HOSE ASSY. | KOBHose Superseded by part number: |
| 8. | ZX22M08062 | [1] | RECEIVER-DRIER | KOBHose |
| 9. | ZX32M12105 | [1] | FLEXIBLE HOSE | KOB |
| 10. | ZH22X12000 | [1] | HYD CONNECTOR | KOB |
| 10-1. | ZD12P02400 | [1] | O-RING | KOB |
| 11. | HH25R12012G3 | [1] | HYD CONNECTOR | KOB |
| 12. | 2444Z4184 | [1] | HYD CONNECTOR | KOB |
| 12-1. | ZD12P02900 | [1] | O-RING | KOB |
| 14. | 2444Z2760 | [1] | HYD CONNECTOR | KOB |
| 15. | ZH42X06000 | [1] | 45 ELBOW,Male, 30° Fl, PF 3/8" x PF 3/8", O-Ring | KOB |
| 15-1. | ZD12P01400 | [1] | O-RING | KOB |
| 16. | ZH32X08000 | [1] | 90 ELBOW,Male, 30° Fl, PF 1/2" x PF 1/2", O-Ring | KOBElbow |
| 16-1. | ZD12P01800 | [1] | O-RING | KOB |
| 17. | ZH32X12000 | [1] | 90 ELBOW,Male, 30° Fl, PF 3/4" x PF 3/4", O-Ring | KOBElbow |
| 18. | 2444Z3405 | [1] | ELBOW | KOB |
| 19. | HH35X16016G1 | [4] | 90 ELBOW | KOB |
| 20. | ZH52X06000 | [1] | TEE,30° Fl, Male, PF 3/8" x 3/8" x 3/8", O-Ring | KOB |
| 21. | YT32H01099P1 | [1] | BRACKET, SUPPORTING | KOBSupport |
| 22. | YT32H01100P1 | [1] | BRACKET, SUPPORTING | KOBSupport |
| 23. | YT32H01098P1 | [2] | CLAMP | KOBClamp |
| 24. | YF30H01023P1 | [1] | GROMMET | KOB |
| 25. | 2420T2948D16 | [1] | U-BOLT | KOBU-bolt |
| 26. | ZM73C10020 | [1] | BOLT,M10x20mm - Course Thread | KOBSems |
| 27. | ZM73C10025 | [4] | BOLT,M10x25mm - Course Thread | KOBSems |
| 28. | ZN18C08007 | [4] | NUT | KOB |
| 29. | YX32H01011P1 | [2] | BUSHING,33mm ID x 49mm OD x 50mm L | KOB |
| 30. | ZS18C10050 | [2] | SCREW,Hex, M10 x 50mm | KOBCap |
| 32. | ZW16H08000 | [2] | WASHER | KOB |
| 33. | ZW16H10000 | [2] | WASHER | KOB |
| 34. | 2436R576F1 | [1] | SOLENOID VALVE | KOBAssy, Check |
| 35. | ZC46X31014 | [1] | CLIP | KOB |
| 36. | PY01P01043D3 | [2] | CABLE TIE,188mm L | KOB |
| 37. | PY01P01043D8 | [1] | CABLE TIE,102mm L | KOB |
| 38. | PY01P01043D6 | [2] | CABLE TIE,4.80mm W x 383mm L | KOB |
| 39. | YJ42H01141P1 | [1] | BUSHING | KOB |
| 40. | 2420Z2185 | [1] | GROMMET | KOBGrommet |
| 41. | LF32H01005P1 | [1] | BRACKET, SUPPORTING | KOBSupport |
| 42. | ZM73C08020 | [2] | BOLT,M8x20mm - Course Thread | KOBSems |
| 43. | YT32H01101P1 | [1] | HYD CONNECTOR | KOB |
| 44. | HH45X16016G1 | [1] | ELBOW | KOB |
