| . . | 24100J10915F1 | [1] | PANEL ASSY, INST | PANEL ASSY, INST |
| 1. | 2414J1139 | [1] | STAND, CONTROL | STAND, CONTROL |
| 1-9. | 2405R61D11 | [2] | BUSHING | KOB |
| 2. | 2416N3378 | [1] | PANEL | KOB |
| 3. | 2416N3438 | [1] | PANEL | KOB |
| 4. | 2418P18643 | [1] | PLATE | KOB |
| 5. | 2416T20760 | [1] | BRACKET | KOB |
| 6. | 2416T20380 | [1] | BRACKET | BRACKET |
| 7. | 2479Z1447 | [1] | SWITCH | KOB |
| 8. | NSS | [1] | NOT SOLD SEPARAT | CONGAUGE, CLUSTER, SEE FIGURE 05-010 |
| 10. | 2479Z214 | [1] | CIGARETTE LIGHTER | KOB |
| 11. | VAME049234 | [1] | RELAY | KOBSTARTER, MITSUBSHI PARTS NO. |
| 13. | 2479U737F3 | [1] | CONTROL | KOB |
| 14. | 2479U346F2 | [1] | IGNITION SWITCH | KOBIgnition |
| 15. | 2421U64 | [1] | TUNER (NOT AVAILABLE) | TUNER (NOT AVAILABLE) |
| 16. | 2479R1366 | [1] | RELAY | KOB |
| 18. | 2414Z266 | [1] | COVER | KOB |
| 19. | 2479U807F2 | [1] | FUSE BOX | KOB Superseded by part number: 2479U807F3 |
| 19-1. | 2479U717S1 | [1] | BASE | HIT |
| 19-2. | 2479U717S2 | [1] | COVER | KOB |
| 19-3. | 2479U717S3 | [1] | PULLER | KOBFuse |
| 19-5. | 2479U807S5 | [4] | FUSE | KOB |
| 19-6. | 2479U717S6 | [6] | FUSE,10 Amp | KOB10 Amp |
| 19-7. | 2479U717S7 | [4] | FUSE | KOB15 Amp |
| 19-9. | 2479U807S9 | [1] | LABEL | KOB |
| 19-10. | 2479U807S10 | [1] | CABLE | KOB |
| 20. | 2447Z156 | [1] | BUZZER | KOB |
| 21. | 2479R1424 | [3] | RELAY | KOBRELAY Superseded by part number: GG90Z00319F1 |
| 22. | 4079Z22 | [1] | RELAY | KOBHORN |
| 23. | 2484R166D5 | [1] | RESISTOR | KOB |
| 24. | 2479U325 | [1] | SWITCH | KOB |
| 26. | 2479U743F7 | [1] | SWITCH | KOBLIGHT |
| 27. | 2479Z1083 | [1] | SWITCH ASSY | KOBIGNITION SWITCH WIPER Superseded by part number: 2479Z1775 |
| 29. | 2479Z1081 | [1] | SWITCH | KOBMODE SELECT |
| 30. | 2420R429D15 | [3] | GROMMET | KOB |
| 32. | 2479U743F5 | [1] | SWITCH | KOBDECEL CANCEL |
| 33. | 2479U743F4 | [1] | SWITCH | KOB2-SPEED SELECT |
| 34. | 2479Z875 | [1] | SWITCH | KOBBUZZER STOP |
| 35. | 2420R429D11 | [1] | GROMMET | KOB |
| 36. | 2479Z1085 | [1] | SWITCH | KOBDECEL SELECT |
| 37. | ZS18C10025 | [2] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 38. | ZS18C06014 | [9] | SCREW,Hex, M6 x 14mm | KOBM06x1.0x14mm |
| 39. | 2420Z1227D1 | [2] | SCREW | KOBM06x1.0x16mm |
| 40. | ZS31C06012 | [14] | SCREW,Phillips Drive, Pan HD, M6 x 12mm | KOBM06x1.0x12mm |
| 41. | 2420T4556 | [4] | SCREW | KOB |
| 42. | ZS31C04010 | [5] | SCREW,Phillips Drive, Pan HD, M4 x 10mm | KOBM04x0.7x10mm |
| 43. | ZS13C10030 | [6] | SCREW | KOBM10x1.50x30mm Superseded by part number: ZS18C10030 |
| 44. | ZW16X10000 | [10] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 45. | ZW16K06000 | [23] | WASHER | KOBID 06 x OD 11.5 x Th 1.6mm |
| 46. | ZW16K05000 | [4] | WASHER | KOBID 05 x OD 10 x Th 1.0mm |
| 47. | ZW16K04000 | [5] | WASHER | KOBID 04 x OD 08 x Th 0.8mm |
| 48. | ZW26X10000 | [12] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 49. | ZW26X06000 | [23] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 50. | ZW26X05000 | [4] | LOCK WASHER | KOBLock -- ID 05 x OD 09 x Th 1.3mm |
| 51. | ZW26X04000 | [5] | LOCK WASHER | KOBID 04 x OD 7.6 x Th 1.0mm |
| 52. | 24100P1724F3 | [1] | THROTTLE | KOB |
| 52-1. | 2416P12051 | [1] | BRACKET | KOBASSY |
| 52-3. | 2418T17877 | [1] | WASHER | KOB |
| 52-4. | R16T0137D2 | [6] | WASHER | KOBCone Disk Spring -- ID 12.2 x OD 25 x Th 1.6mm |
| 52-5. | R16T0040 | [1] | WASHER | KOB Superseded by part number: 2418T12345, 77266155 |
| 52-6. | 2425Z519 | [2] | BALL | KOB |
| 52-7. | 2417T519 | [1] | SPRING | KOB |
| 52-8. | ZS18C12035 | [1] | SCREW,Hex, M12 x 35mm | KOBM12x1.75x35mm |
| 52-10. | ZN32C12011 | [1] | NUT | KOB |
| 52-11. | ZN18C12007 | [1] | NUT | KOBM12x1.75mm |
| 52-12. | ZN18C06005 | [1] | NUT | KOBM06x1.0mm |
| 52-13. | 2406P4071 | [1] | LEVER & PIN ASSY | KOB |
| 52-14. | 2420T7001 | [1] | BOLT | KOB |
| 53. | 2405T1330D1 | [1] | BUSHING | KOB |
| 54. | 2406R252 | [1] | GRIP | KOB |
| 56. | 2480U178 | [1] | CONTROL | KOB |
| 57. | 2480Z228 | [1] | RESISTOR | KOB |
| 58. | ZS18C10014 | [4] | SCREW,Hex, M10 x 14mm | KOBM10x1.50x14mm |
| 59. | 2479R656 | [1] | WIRE HARNESS | KOBCODE |
| 60. | 2420Z1232 | [1] | NUT | KOBM12x1.25mm |
| 61. | 2420Z1226D1 | [6] | SCREW | KOBMACHINE |
| 62. | 2420Z1225D1 | [2] | SCREW | KOB |
| 63. | 2418Z726D3 | [2] | WASHER, LOCK | KOBID 06 x OD 12.2 x Th 1.5mm Superseded by part number: ZW26X06000 |
| 64. | 2418Z726D2 | [6] | LOCK WASHER | KOBID 05 x OD 9.2 x Th 1.3mm Superseded by part number: ZW26X05000 |
| 65. | 2418Z726D1 | [2] | LOCK WASHER | KOBID 03 x OD 5.9 x Th 0.7mm Superseded by part number: ZW26X03000 |
| 66. | 2418Z725D3 | [2] | WASHER | KOBID 06 x OD 11.5 x Th 1.6mm |
| 67. | 2418Z725D2 | [6] | WASHER | KOBID 05 x OD 10.0 x Th 1.0mm |
| 68. | 2418Z725D1 | [2] | WASHER | KOBID 03 x OD 06.0 x Th 0.5mm |
| 69. | 2484R165 | [1] | CONDENSER | KOB |
| 70. | 2479R1347 | [1] | HARNESS | KOB |
| 72. | 2432T3991 | [1] | LABEL | LABEL |
| 74. | 2432T2473 | [1] | LABEL | KOB |
| 75. | 2432T3992 | [1] | LABEL | KOB |
| 78. | 2420Z1030D2 | [1] | KIT | KOBPLATE Superseded by part number: PM50S01001P1 |
| 79. | 2479Z1454 | [1] | THERMOSTAT | KOBHEAVY LIFT |
| 80. | 2432T2527 | [1] | LABEL | KOB |
