纽荷兰零件查询(E80BMSR) - CRAWLER EXCAVATOR ASN LF05-04001 - (N8TA18060) (120-17[1]) - CONTROLS, OPERATORS New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
814 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LF03M00011F1 | [1] | Controls, Operators | |
| . . | YB03M00036F1 | [1] | Control Box Assy (See Fig No.125-18-1) | |
| . . | YN03M01974F1 | [1] | Grip Assy (See Fig No.127-01-1) | |
| . . | YN50E00018F1 | [1] | Switch Instal (See Fig No.129-17-1) | |
| . . | LF50M00001F1 | [1] | LEVER | KOBLever Assy, Propel (See Fig No.138-18-1) |
| . . | YT55M00007F1 | [1] | Pedal Assy (See Fig No.139-18-1) | |
| . . | YN54E00010F1 | [1] | Radio Instal (See Fig No.129 -17-1) | |
| . . | YT12P01062F1 | [1] | Clamp Assy (See Fig No.132-18-1) | |
| . . | YN25M01183F1 | [1] | ARMREST | KOBArm Rest (See Fig No.132-18-1) |
| . . | LF03M00013F1 | [1] | Controls, Operators | |
| 1. | YN03M01859P2 | [1] | SUPPORT | SM |
| 2. | YB26M00002P1 | [1] | FLOOR MAT | KOB |
| 3. | YN03M01943F2 | [1] | COVER ASSY | KOB |
| 4. | YN03M01945F1 | [1] | GUARD | SMCover Assy |
| 5. | YN03M01946F1 | [1] | GUARD | SMCover Assy |
| 6. | YB25M01010P2 | [1] | STAND | KOBSeat |
| 7. | YN25M01161F1 | [1] | GUIDE | SMRail Assy |
| 8. | YN20M01356P1 | [1] | DIFFUSER | KOBGrille |
| 9. | ZM73C10025 | [5] | BOLT,M10x25mm - Course Thread | KOBSems, Serial Range: LF05-04001-LF05-04010 |
| . . | ZM73C10020 | [5] | BOLT,M10x20mm - Course Thread | KOBSems, Start Serial: LF05-04011 |
| 10. | ZS28C08016 | [4] | SCREW,Hex Socket Head, M8 x 16mm | KOBCap |
| 11. | ZW26K08000 | [4] | LOCK WASHER | KOB |
| 12. | ZW16P08000 | [4] | WASHER | KOB |
| 13. | ZS28C08020 | [4] | SCREW,Hex Socket Head, M8 x 20mm | KOBCap |
| 14. | YN02C02055P1 | [1] | TRAY | KOBAsh |
| 15. | ZM66C06016 | [9] | BOLT | KOBSems |
| 16. | ZM73C08025 | [2] | BOLT,M8x25mm - Course Thread | KOBSems |
| 17. | YB03M01019P1 | [1] | PLATE | KOB |
| 18. | ZM73C08016 | [2] | BOLT,M8x16mm - Course Thread | KOBSems |
| 19. | YN20M01643P1 | [1] | SPRING | SM, Serial Range: LF05-04001-LF05-04091 Superseded by part number: YN20M01643P2 |
| . . | YN20M01643P2 | [1] | GAS STRUT,271mm Extended, 181mm Compressed | KOB, Start Serial: LF05-04092 |
| 20. | YT03M01222P1 | [1] | GROMMET | KOB |
| 21. | PY52F01022D7 | [1] | TRIM PANEL | KOB |
