神钢零件查询(MD200BLC) - EXCAVATOR ASN YQU0001 (1/80-12/06) (10-002) - ELEMENT KIT Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
312 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24046Z72F2 | [1] | ELEMENT KIT | |
| 7. | 2446R332D6 | [1] | ELEMENT, BYPASS | ELEMENT, BYPASS |
| 8. | 2421Z302 | [2] | BRUSH, PAINT | |
| 9. | 2421R176D2 | [1] | PARTS MANUAL | |
| 10. | 2421R179D2 | [1] | MANUAL, OPERATORS | |
| 11. | 2421R177D2 | [1] | PARTS MANUAL | |
| 12. | 2421R178D2 | [1] | MANUAL, OPERATORS | |
| 13. | 2446R332D2 | [1] | ELEMENT, FILTER, OIL | ELEMENT, FILTER, OIL |
| 14. | 2446R332D4 | [1] | FILTER | KOB Superseded by part number: 47500495 |
