凯斯零件查询(2355) - PRECISION AIR CART (11/15-) (61.800.AC[09]) - METER MODULE WITH MOTOR, COARSE Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
848 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47357789
|
[1] |
MOTOR-PUMP
|
SAS
Meter Drive Superseded by part number: 47842008
|
| 2. |
86511953
|
[4] |
BOLT,Hex Serr, M6 x 25mm
|
WIN
|
| 3. |
47357732
|
[1] |
MODULE
|
SAS
Meter, Full Coarse, Incl 4 - 22 Superseded by part number: 47891163
|
| 4. |
10977727
|
[3] |
BOLT,Hex, M5 x 14mm, Cl 8.8, Full Thd
|
MOD
Superseded by part number: 10977721
|
| 5. |
47779527
|
[1] |
CARTRIDGE
|
SAS
Meter Roller
|
| 6. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Seed Gate Insert, Incl in 3
|
| 7. |
9840589
|
[2] |
O-RING,0.07" Thk x 1.489" ID, -29, Cl 6, 90 Duro
|
WIN
|
| 8. |
47543003
|
[1] |
METER
|
SAS
Module, Incl 9 - 22 Superseded by part number: 47891161
|
| 13. |
47543024
|
[6] |
O-RING
|
SAS
|
| 16. |
47357750
|
[1] |
BEARING ASSY
|
SAS
Bearing
|
| 17. |
47357780
|
[2] |
LOCK
|
SAS
Lock, Roller
|
| 18. |
47695946
|
[2] |
BUSHING
|
SAS
Roller Cartridge
|
| 22. |
47357767
|
[6] |
LINKAGE
|
SAS
Manifold Gate Superseded by part number: 47891167
|
